6
Use the steps provided to install the handle assembly.
Secure the handle to valve by aligning the thin
tooth on handle with the thin slot on valve
shaft.
Insert the screw into handle & tighten with a
3/8” socket & ratchet. Align and press handle
plug into slot to cover screw.
Completed assembly will look like picture
above.
Step 2
Step 3
Step 1
Valve: Installation: Handle
