USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Page 29 of 36 Super Pump VS Pump IS2603VSP Rev-A
10.2. Parts Listing
Ref.
No.
Part No. Description Qty.
1 SPX1600PN Swivel Nut & Hand Knob 2
2 SPX1600D Strainer Cover 1
3 SPX1600S Strainer Cover Gasket 1
4 SPX1600M Basket 1
5 SPX1700FG Drain Plug with Gasket 2
6 SPX1600AA Pump / Strainer Housing With Gasket 1
7 SPX1600R Diffuser Gasket 1
8 SPX2600B Diffuser 1
9 SPX2610C Impeller 1
10 SPX1600Z2 Shaft Seal Assembly 1
11 SPX1600T Housing Gasket 1
12 SPX2600E5 Seal Plate 1
13 SPX1600F5 Motor Mounting Plate 1
14 SPX0125z44 Motor Cap Screws (Set of 4) 1
15 SPX1600Z4 Housing Cap Screw 4
16 SPX2600G1 Mounting Foot (Includes Screws) 1
17 SPX1600Z52 Mounting Foot Screws (Set of 2) 1
18 SPX3400DR4 Motor Drive Display Cover (Cover only) 1
- SPX3200LCD Digital Control Interface Assembly 1
- SPX3400DRKIT Wall Mount Kit 1
- SPXHKIT3 Quick Fix Kit (Includes #3, 7, 10, 11 & Jack’s Lube) 1
POWER END
- SPX2603Z1VSPE Power End Assembly (Includes #7-14, motor and drive) 1
* WHISPERFLO is a registered trademark of Pentair Aquatic Systems, which is used herein for identification purposes
only. This is a retrofit base for existing WHISPERFLO pump installations. Pentair Aquatic Systems is not affiliated
with Hayward Pool Products.
