MagicBowl
Water Feature
Niche
Pool/Spa
Drain
Line
1" PVC
Electrical Line
1" PVC
Water Line
1½" PVC
Check Valve
Flow Control
Valve
Junction
Box
Low Voltage
Transformer
From
Pump
To Wall Switch
or
Omni Control
NOTE: Image not drawn to scale
3
