HBM AE301 - 2 Mounting and Dismounting

8
Clip
HBM A0114-6.3 en
2 Mounting / Dismounting
The housings are installed onto mounting rails to DIN EN 50 022; they are
hooked onto the upper edge and snapped into the spring plate on the lower
edge.
For dismounting, use a screwdriver to push down the spring plate and unhook
the housing.
Hook in
Lock
Mounting rail
Mounting Dismounting
Fig. 2.1: Mounting / Dismounting
