Before connecting the machine
to
the mains, make sure
that the electrical values of the mains supply are the
same as
those
for
the
machine's electrical components.
Use the wiring
diagram
(Fig. 11) for connecting the lathe
to the mains supply.
WARNING!
Make sure the machine is properly ground!
failure to do so may cause serious injury and
damage to user!
DC-Motor
- its type is 91ZYT005, 230V, 5600rpm, 2.7A,
750W
A
Make sure that all 2 phase (L, N) are connected.
Defective
or incorrect
connection will render
the
C
guarantee null and void.
lndicators are:
Motor runs hot immediately (3-4 minutes).
Motor doesn't run silently and has no power.
Magnetic Switch
(A, Fig .12) has the function of
emergency
stopping and the protective
function
to the
machine and electric components. Green push button
marked "I" to start the motor, Red push button marked
"O" to switch the motor off.
Speed Control Knob (B, Fig. 12) turn it clockwise to
increase the spindle speed, reverse
to decrease.
The
knob should be turned to zero each time the machine
is
stopped. Always start
the machine with the knob set
at zero.
F/R switch
(C, Fig.12) changing the
position of
switch
will reverse the direction of the motor. F-forward
direction, R- reverse direction.
Fuse
Base
(D, Fig. 13) located on the back plate of
electrical box. Fuse what rate is SA is put in the base.
Turn counter-clockwise
the button to open
and
change the fuse, reverse to retighten
.
.&.,
WARNING!
This machine is designed and intended for use by
properly trained and experienced personnel only! If
you
are not familiar with the proper and safe use of
mill/drills, don't use the machine until proper training
and knowledge have been obtained!
Failure to comply may cause serious injury!
- 10
-
Fig.12
Fig.13
