2. Remover the cover of drawbar onto the motor
cover (A, Fig, 14).
3.
Hold
the fiat
of spindle
(B,
Fig.15)
to keep it from
moving while loosening the drawbar with the
22-25
spanner in toolbox.
4.
Loosen the drawbar approximately three to four
full
turns.
5. Tap the drawbar
head with a
rubber mallet
to
dislodge the arbor.
6. Grasp the arbor with on hand while loosening the
drawbar
with
the other.
Continue
to loosen
the
drawbar until the arbor can be withdrawn from the
spindle. Wipe out the spindle with a clean dry rag.
7.
Wipe down the new arbor with
a
clean dry rag
and place
the arbor into the
spindle. Thread
the
drawbar into the arbor. Tighten the drawbar with a
spanner
while holding the spindle.
WARNING!
Do not loosen the drawbar more than three or four
turns before hitting with a
rubber
mallet.
Damage to the drawbar threads may occur!
GIBS ADJUSTMENT
After a
period of time,
movement of the table over
the
ways will cause normal wear. Adjust the gibs to
compensate for this wear.
1.
The horizontal gib adjustment screw (A, Fig.17) is
found to the rear right on table. The traverse gib
adjustment screw (B, Fig.17) is found on the right
side of saddle under the table. The vertical gib
adjustment screw (C, Fig.18)
is
found onto the
column.
2. Loose the screw from small taper end of gib. Turn
the
screw from large taper end of
gib
slightly
clockwise to tighten. Tum the table handwheel and
check the tension.
- 11 -
C
Fig.
14
Fig.
15
