15.6" LCD Color Monitor HCL HCMDLWBT21&HCMDLWBN21
15
5.2 Electrical Block Diagram
Main Board
Panel Interface
(CN601)
Crystal
24MHZ
(X401)
MCU RTD2120L
(U401)
Scalar RTD2025L
(Include ADC, OSD)
(U501)
D-Sub Connector
(CN301)
H sync
V sync
RGB
EEPROM
M24C16
(U403)
Key Button
(CN202)
