HCL HCMDLWBT21 User Manual

15.6" LCD Color Monitor HCL HCMDLWBT21&HCMDLWBN21
61
12. Different Parts List
HCMDLWBT21
Diversity of T682RDDCWXKCNN compared with T68MRDDCWXKLNN
Location TPV Part No. Description
041G 68508 A CONTROL CARD
750GLV156B1114N000 PANEL TPM156B1-L01 C1A FZ TPV
Q15G0248601 MAINFRAME
Diversity of T683RDDCWXKCNN compared with T68MRDDCWXKLNN
Location TPV Part No. Description
041G 68508 A CONTROL CARD
052G 1207 A CONDUCTIVE TAPE 45MM *25MM *0.08MM
E09502 095G8014 6JH09 WIRE HARNESS 6P(PH)-6P(PH)
750GLV156WX114N000 PANEL TPM156B1-WX101TB A1 FZ TPV
CBPC8VRDA1Q1 MAIN BOARD
Q15G0248601 MAINFRAME
Diversity of T68VRDDCWXKLNN compared with T68MRDDCWXKLNN
Location TPV Part No. Description
041G 68508 A CONTROL CARD
052G 1207 A CONDUCTIVE TAPE 45MM *25MM *0.08MM
E09502 095G8014 6JH09 WIRE HARNESS 6P(PH)-6P(PH)
E750 750GLD156WX111N000 PANEL SVA156WX1-01TB SH SVA
CBPC8VRDA1Q1 MAIN BOARD
HCMDLWBN21
The BOM of T67MRDNCWXKLNN is the same as T67MRDNCWXLHNN’s.
Diversity of T68VRDNCWXLHNN compared with T67MRDNCWXLHNN
Location TPV Part No. Description Remark
041G 68508 A CONTROL CARD
052G 1207 A CONDUCTIVE TAPE 45MM *25MM *0.08MM
E09502 095G8014 6JH09 WIRE HARNESS 6P(PH)-6P(PH)
E09502 095G8014 6WH09 WIRE HARNESS 6P(PH)-6P(PH) 2nd source
E750 750GLD156WX111N000 PANEL SVA156WX1-01TB SH SVA
E750 750GLD156WX121N000 PANEL SVA156WX1-01TB REV.B SH SVA 2nd source
CBPC8VRDA1Q1 MAIN BOARD
Q41G500074315A MANUAL
