11. BOM List
HCMDLWBT21 T68MRDDCWXKLNN
Location Part no. Description
040G 581743 1A LOGO LABEL
050G 600 2 HANDLE1
050G 600 3 HANDLE2
052G 1150 C INSULATING TAPE
052G 1185 1 BIG TAPE
052G 1186 SMALL TAPE
052G6019 1 INSULATING TAPE
E08902 089G 725CAA DB D-SUB CABLE
E08902 089G 725GAA DB D-SUB CABLE 2ND SOURCE
E08902 089G 725HAA DB D-SUB CABLE 2ND SOURCE
089G417A15N IS POWER CORD
E09502 095G8014 6JH02 WIRE HARNESS 6P-6P
E09502 095G8014 6WH02 WIRE HARNESS 6P-6P
095G8018B3D516 LVDS CABLE
0M1G 130 5120 SCREW
0M1G1730 6120 SCREW,42-D020523
705GQ834105 LCD 15.6" STAND-BASE ASS'Y
AM1G1740 12 47 CR3 SCREW
Q34G0266ABJ 1B0100 STAND TOP
Q34G0267ABJ 1B0120 STAND
Q34G0268ABJ 1B0133 BASE 8S1
Q37G0067012 HINGE
750GLM56B1112N PANEL M156B1-L01 NB CMO
AM1G1740 12225 CR3 SCREW
CBPC7MRDA3Q1 CONVERSION BOARD
040G 45762412B CBPC LABEL
CN202 033G3802 6 WAFER
CN201 033G3802 9 WAFER 9P RIGHT ANELE PITCH
CN601 033G8027 14 H WAFER 14P 2.0MM DIP
R507 061G152M339 64 CHIPR 3.3 OHM +-5% 2W
C405 067G 3151007KV
ELCAP 10UF M 50V 105℃ KINGNICHI
C203 067G 3151014KV
EC 105℃ CAP 100UF M 25V
C202 067G 3151014KV
EC 105℃ CAP 100UF M 25V
C505 067G 3152207KV
ELCAP 22UF M 50V 105℃ KING NICHI
C604 067G 3154704KV
ELCAP 47UF M 25V 105℃ KINGNICHI
CN301 088G 35315F H D-SUB 15PIN 2ND SOURCE
CN301 088G 35315F HD D-SUB CONN F ATTACHED SCREW
