15.6" LCD Color Monitor HCL HCMDLWBT21&HCMDLWBN21
43
ZD301 093G 39S 34 T UDZSNP5.6B ROHM
ZD302 093G 39S 34 T UDZSNP5.6B ROHM
ZD303 093G 39S 34 T UDZSNP5.6B ROHM
ZD305 093G 39S 34 T UDZSNP5.6B ROHM
ZD307 093G 39S 34 T UDZSNP5.6B ROHM
715G2498 1 AO MAIN BOARD PCB
KEPC7QAK KEY BOARD
CN001 033G3802 6H WAFER 6P RIGHT ANGLE PITCH 2.0
SW001 077G 600 1GCJ TACT SWITCH TSPB-2 -NP
SW002 077G 600 1GCJ TACT SWITCH TSPB-2 -NP
SW003 077G 600 1GCJ TACT SWITCH TSPB-2 -NP
SW004 077G 600 1GCJ TACT SWITCH TSPB-2 -NP
SW005 077G 600 1GCJ TACT SWITCH TSPB-2 -NP
SW001 077G 600 1A CJ TACT SWITCH 2PIN
SW002 077G 600 1A CJ TACT SWITCH 2PIN
SW003 077G 600 1A CJ TACT SWITCH 2PIN
SW004 077G 600 1A CJ TACT SWITCH 2PIN
SW005 077G 600 1A CJ TACT SWITCH 2PIN
SW005 077G 600 1A HJ TACT SWITCH 5PIN
SW003 077G 600 1A HJ TACT SWITCH 5PIN
SW004 077G 600 1A HJ TACT SWITCH 5PIN
SW002 077G 600 1A HJ TACT SWITCH 5PIN
SW001 077G 600 1A HJ TACT SWITCH 5PIN
D001 081G 12 1F GH 1ED 3PIN Φ3 YELLOW/GREEN GHZYG603D2-5B
D001 081G 12 1F GP LED 3Φ YELLOW/GREEN GP32032M/G307-ZY-50-C
R003 061G0603000 1F RST CHIPR 0 OHM +-1% 1/10W
R005 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R004 061G1206200 1F RST CHIPR 2.0 KOHM +-1% 1/4W
R002 061G1206200 1F RST CHIPR 2.0 KOHM +-1% 1/4W
715G2835 1 KEY BOARD PCB
PWPC8521VYD1 POWER BOARD
040G 45762412B CBPC LABEL
CN802 033G8021 2E F WAFER
CN801 033G8021 2E F WAFER
051G 6 4503 GLUE_RTV
IC902 056G 139 3A IC PC123Y22FZ0F
NR901 061G 58080 WT 8 OHM NCT
R908 061G152M10452T RST MOFR 100KOHM +-5% 2WS
C908 063G107K2246S1 X2 CAP 0.22UF K 275VAC
C904 063G107K2246S1 X2 CAP 0.22UF K 275VAC
