headway EDB-2 - EDB-2 Top Panel Controls and Indicators; Power Controls and Status Indicators; Equaliser and Filter Controls; Input and Output Management


4

LOWBATTERYLED
LightsBLUEwhen
Baeriesarewithin
hoursofexpiring
EARTH/GROUNDLIFT
PreventsHumLoopby
DisconnecngPin1from
XLROUT
HEADWAYEDB‐2TopPanel
POWERON/OFF/STANDBY
GreenLED
IndicatesPower
PauseinStandbyPosionto
ReducePoweron“Thump”

MASTER
SetsOutputLevel
toLINEOUT
&XLROut

MUTE
TurnsOFF
OutputSignals
Re.RedLED.
LIVEDenotes
Pre‐Amp
OutputON
NOTCHFILTER
‐12dBNotch

Q=Bandwidth
Freq.=Centre
Frequencyofcut.
Switches:CH.1CH.2or
OFF

5BANDEQ
SWITCH

Assigns5BandEQ
toCH.1orCH.2
orBOTH

XLRSWITCH/MICIN
18vPhantomON
PhantomOFF
XLROFF
RANGEFILTER
(HighPassFilter)
VIOLIN@192Hz
GUITAR@85Hz
BASS@41Hz

PHASE
ReversethePhase
ofCH.1orCH.2Signal.
An‐FeedbackOpon
INPUTIMPEDANCE
+HI&HI‐PassivePickups.
Acve/LOW‐Poweredor
LowImpedancePickups
Switches:CH.1&CH.2
INPUTGAIN
0dB‐+32dB
CH.1&CH.2
Bass@120Hz+/‐12dB
AsAbove@45Hz+/‐16dB

5BANDEQ
Treble@10kHz+/‐13dB

Pres@2.8kHz+/‐7dB
H.Mid@880Hz+/‐12dB
L.Mid@590Hz+/‐13dB



