headway EDB-2 - EDB-2 Panel Layout and Connectivity; Right Hand Side Panel Connections; Front Panel Inputs and Options; Rear Panel Connections and Battery Access


5

EDB‐2RHSidePanel LINEOUT
LowImpedance
MonoMixJackOut
AUXIN/iPODINPUT
3.5mmMiniJack
PostEQtoMasterVol.


EDB‐2RearPanel
DI/XLRLINEOUT
BalancedLine
OutputXLR(MonoMix)
*
ThisdoesNOTacceptPhantomPower
FromMixer*
EXT.POWERIN
18vAC/DCAdapterInputConnector
UseONLYHeadwayEDB‐PSU
BATTERYPANEL
(PP3/6F22x2)
WithCapveScrew
EDB‐2FrontPanel
PHANTOMPOWER
TOCH.1
JACKINSWITCH
CH.1JACKIN
MonoIN
(RefertoInputImpedance
Switch&PhantomPower
Switch)
CH.2MONOJACKIN
RoutesStereotoBoth
ChannelsifNoJackinCH.1
CH.2MIC/XLRIN
Balancedwith
18vPhantom
PowerOpon.
SeeXLRSwitch:
XLROff/On
PhantomOn
OPTIONS
BeltClip(asshown)or
MicStandAdaptor19/32”(15mm)
