14EPU‐DInstallationandOperationManual
059840‐00Rev.A Heat‐TimerCorp.
MountingtheEPU‐DModule
MountingtheEnclosure
1. SelectanappropriatelocationtomounttheEPU‐D.Thelocationmustmeetthefollowingminimum
requirements:
• Themountingsurfaceshouldbeflatandstrongenoughtoholdtheweightofthedevice.
• Thedevicecanbemountedamaximumof500feet(152.4meters)fromthesensorlocation,butshould
bemountedasnearaspossibletoavoidexcessivewireruns.
• DONOTmountthedeviceinalocationwhereitwillbeexposedtoextremeheat,cold,humidity,or
moisture.
2. RemovetheEnclosureWiringCover(1)byremovingthetwolowerscrews(2)holdingittothebase(3),
andthenremovetheDisplayModule(4)byremovingthetwomiddlescrews(5)holdingittothebase.
Figure4: EPU‐DControlModulePartsDiagram
1
2
3
4
5
5
