2
CONTENTS
CONTENTS
Part 1 – Product and Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Part 2 – How The Phoenix Evolution Operates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Part 3 – Prepare Water Heater Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
A. Installations Must Comply With:
B. Before Locating the Phoenix Evolution
C. Clearances for Service Access
D. Residential Garage Installation
E. Exhaust Vent and Intake Air Vent
F. Prevent Combustion Air Contamination
G. When Removing a Water Heater from an Existing Common Vent System
H. Water Chemistry for Hydronic Heating Module and Domestic Hot Water
Part 4 – Domestic Water Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-16
A. Temperature and Pressure Relief Valve for DHW
B. Domestic Hot Water Expansion Tank
C. Domestic Water Piping
D. Phoenix Evolution Piping
E. Mixing Valve Installation
F. Auxiliary Piping
Part 5 – Hydronic Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-22
A. Hydronic Piping Module
B. Pressure Relief Valve for the Hydronic System
C. Hydronic Expansion Tank and Make Up Water
D. Hydronic Heating Module System Piping
E. Hydronic Heating Module Output
Part 6 – Field Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-26
A. Field Wiring Compliance Requirements
B. Field Wiring
C. Line Voltage Wiring
D. Low Voltage Wiring
E. Field Connection Board
F. Internal Wiring
Part 7 – Gas Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-28
A. Gas Supply
B. Gas Piping
C. Gas Table
D. Dung’s Gas Valve
E. How to Verify Combustion
Part 8 – Venting, Combustion Air and Condensate Removal. . . . . . . . . . . . . . . . . . . . 29-36
A. General
B. Installing Exhaust Vent and Intake Air Vent
