CONTROL OVERVIEW
PART 9: CONTROL OVERVIEW (CONTINUED)
CLOCK DATE
08/28/2009 Fr 10:01A
D. PROGRAMMING THE SYSTEM SETTING
Note: Programming of the control is not possible when the unit is firing. Make sure any input such
as the thermostat is turned off, so the boiler will remain idle to allow programming.
To access The System Setting Program the user will need to press the ENTER Key for 4 seconds until
the display shows the following:
ENTER MENU CODE
000
Using the arrow keys on the display, log in your System Menu Access Code “925”. To confirm code,
press the ENTER KEY to access System Setting Program Navigation menu.
ENTER MENU CODE
925
E. SYSTEM SETTING PROGRAM NAVIGATION
Once the System Menu Access Code is confirmed, the user can now start to set the System
Parameters Menu. Use the arrows keys on the display to navigate through the different program set-
tings. To change a setting, press the ENTER KEY to change an appliance setting. System settings can
be increased by pressing the UP ARROW and decreased by pressing the DOWN ARROW on the dis-
play. Listed below are the System Settings that can be programmed into the control.
Function 1
Factory Program Mode
MODE 1
PHOENIX
This screen indicates that the control is configured correctly. Do not change this screen
Function 2
Max Tank Temp
MAX TANK TEMP 2
180 °F
Description: Sets the overall all tank temperature maximum limit. Factory Default of 180 °F (Range
95 °F to 185 °F)
Function 3
DHW Offset Temp
OFSET 3
0 °F
Description: Not Used.
40
