FEATURES

• Automatically comes on when motion is de-

tected.

• Automatically turns light o.

• Dusk Accent lighting.

• Photocell keeps the light o during daylight

hours.

is package includes:

• Coach Light

• Mounting Bracket and Screws

• Wire Connectors

• Owner’s Manual

REQUIREMENTS

• e light control requires 120 volts AC.

• If you want to use Manual Mode, the control

must be wired through a switch.

• Some electrical codes require installation by

a qualied electrician. Please check the codes

in your area.

Model 4167

Before installation, record the model num-

ber listed inside the xture. Attach receipt

in case of possible warranty issues.

Model Number:

© 2013 HeathCo LLC 200471-02A

Installation and

Operating Instructions

DualBrite® Motion

Sensing Coach Light

Coach Light

Other manuals for Heath Zenith DualBrite

Installation And Operating Instructions24 pages
