3
200471-02
Black to black
White to white
Recommended Grounding Method
Use a green ground “pigtail” (not provided) and
twist one end together with the bare xture wire
and the box ground wire. Secure with a wire
connector. Secure the other end of the “pigtail”
with the GND screw on the mounting plate.
Connect the xture wires to the wires in the junc-
tion box. Twist the wires together and secure with
wire connectors.
If you have metal junction box, you may not need
the green “pigtail”. If you are unsure about the
grounding method, consult your local building
code.
To Next Page
