SB-102-19: Relays Chatter in VOX Mode
August 7, 1978
SB-102
Bulletin No:SSB Transceiver
SB-102-19
This may occur when the VOX gain is in the near-full CW position w
ith
the MIC level
advanced past the 12 o'clock position. Also, the un
it will not return to receive when the
operator stops talking.
Check the tube at V1. A "GE" tube will oscillate, thus causing the ab
ove problem.
Other …(rest is missing)
SB-102 Service Bulletins
Page 182
181
183
Table of Contents
Heathkit HW-101 and SB-10X Restoration and Troubleshooting
1
Table of Contents
3
A)History of the HW-101
14
A.1.The SB-Series and HW-Series (Wikipedia)
15
A.2.Comparison of Various Models
16
A.3.Sb Series Vs HW Series
16
A.3.1.Rf Amp and 1St Receiver Mixer
17
A.3.2.Sb-101/SB-102 LMO Power Source
18
A.3.3.Sideband Bias Circuit
18
A.3.4.Accessory Socket
18
A.3.5.Cw Filter
18
A.3.6.Sb-102 Vs. HW-101
19
A.3.7.Power Supply
20
B)General Inspection and Restoration Checklist
21
B.1.Initial Inspection and Cleaning
21
B.2.Resistance and Voltage Checks
23
B.3.Receiver Alignment
24
B.4.Transmit Alignment
24
B.5.Meter Checks
24
B.6.Final Checks (Optional)
24
C)General Troubleshooting Tips
26
C.1.The Unit Appears Completely Dead
26
C.2.Does the Unit Receive
26
C.2.1.Unit Does Not Receive at All
26
C.2.2.Unit Receives on some Bands but Not Others
27
C.3.Transmitter Troubleshooting
27
D)Transmit Tuning and Operation
28
D.1.Initial Transmit Tune-Up
28
D.2.Single Sideband Operation
29
D.2.1.Ptt Adjustments
29
D.2.2.Vox Adjustments
29
D.3.Cw Operation
30
E)Alignment
32
S.2.1.Final Heterodyne Oscillator Alignment
38
S.2.2.Driver Neutralization Adjustment
38
S.3.Lmo Shifter Adjustment
39
T)Uneven Response Across the Band / Bandpass Filter
40
To 8895 Khz Bandpass Filter
40
T.1.1.Measuring the Bandpass Filter Response (Simple Method)
41
T.1.2.Measuring the Bandpass Filter Response (Sweep Analysis)
41
U)Signal Level Measurements
44
U.1.Receive Signal Levels
44
U.1.1.Carrier and Heterodyne Oscillator Levels
44
U.1.2.Receive Audio Signal Levels
45
Levels)
45
V)Using an Audio Signal Generator at 1 Khz, Connect the Generator to the Top of the AF Gain Control and Adjust the AF Gain Control to Provide 500 Mw Audio Output
45
V.1.1.Receive RF and if Signal Levels
45
V.2.Transmit Signal Levels
49
V.2.1.Transmit and VOX Audio Level Troubleshooting Guide
49
V.2.2.Transmit RF Signal Levels
50
W)Signal to Noise Ratio (SNR)
52
W.1.Signal to Noise Ratio (Theory)
52
W.1.1.Concept of Signal to Noise Ratio SNR
52
W.1.2.Signal to Noise Ratio
52
W.1.3.Effect of Bandwidth on SNR
53
W.1.4.Signal to Noise Ratio Specifications
53
W.2.Measuring Signal to Noise Ratio (SNR)
54
W.2.1.Required Equipment
54
W.2.2.Test Setup
55
W.2.3.Test Methodology
55
X)Testing Gain, S+N/N, AGC Threshold and Figure of Merit
58
X.1.Testing
59
X.1.1.Receiver Gain
59
S+N)/N Testing
59
X.1.3.Agc Threshold
59
X.1.4.Agc Figure of Merit
60
X.2.Summation
60
Y)Heathkit "S" Meter Circuit
61
Y.1."S" Meter Vs. AVC Voltage
62
Y.2.Avc and "S" Meter Calibration
63
Z)Servicing Procedures
64
Z.1.Front Panel Remove and Replace
64
Z.1.1.Front Panel Removal
64
Z.1.2.Front Panel Installation
65
After the Panel Is Installed
65
After the Panel Is in Place
65
A)During this Procedure, be Especially Careful Not to Place too Much Pressure on the Main Tuning Dial
66
B)During this Procedure, be Especially Careful Not to Place too Much Pressure on the Zero Set Shaft
66
Z.2.Front Panel Escutcheon Mounting
67
Z.3.Sb Series Dial Mechanism
69
Z.3.1.Installation of the Spiral Groove Follower Mechanism
69
Z.3.2.Installation of Circular Dial on LMO Shaft
69
Down. Retighten the Screws
70
Drive Arm Base up or Down. Retighten the Screws
70
Pointer Is at the "5" Marking. Retighten the Screws
71
The Dial Pointer Is at the "5" Marking. Retighten the Screws
71
Ab.1.1.Dial Calibration
71
Ab.1.2.Re-Engaging the Main Tuning Pulley
71
Ab.1.3.Drag When Rotating Main Tuning Knob
73
Ab.1.4.Circular Dial Wobble
74
Ab.1.5.Spiral Groove Nylon Follower Replacement
75
Ab.1.6.Zero Set Dial Mechanism and Pulley
76
Ab.1.7.Repairing the Center Hub
78
Ab.2.Knob Inlays
80
Ab.3.Pa Load Capacitor Remove and Replace
81
Ab.4.Function Switch (A.C. Switch)
82
Ab.4.1.Finding a Replacement AC Switch
82
Ab.4.2.Replacing the AF Gain with a Control Having an AC Switch
82
Ab.4.3.Modifying the Failed Switch with a Microswitch
82
Ac)Modifications
84
Ac.1.Conversion to Low-Z Headphones
85
Ac.2.Improved CW Operation
86
Ac.3.Transmit Improvements
88
Ac.4.Receive Improvements
90
Ac.5.Bfo Level to Product Detector
90
Ac.6.I.f. Filter Passband Improvements
92
Ac.7.Stabilizing Meter Zero Settings
94
Ac.8.Antenna Connector
96
Ac.8.1.Bnc Connector
96
Ac.8.2.So-239 Connector
96
Ac.8.3.So-239 to RCA Male Adapter
97
Ac.9.Sb-100 CW Filter Modification
98
Ac.10.Using an External VFO for Split Frequency Operation
100
Ad)Heathkit Filters
101
Ad.1. Heathkit Filter Measurements
102
Ad.2.Ssb Filter 404-200 Circuit
104
Ad.3.Ssb Filter 404-283 Circuit
105
Ae)Printed Circuit Boards (Pcbs)
107
Ae.1.Modulator Printed Circuit Board 85-127-X
109
Ae.1.1.85-127P221 (SB-100, SB-101)
109
Ae.2.If Printed Circuit Board 85-128-X
110
Ae.3.Bandpass Printed Circuit Board 85-129-X
111
Ae.3.1.85-129P223 (SB-100)
111
Ae.4.Audio Printed Circuit Board 85-130-X
112
Ae.4.1.85-130P224 (SB-100, SB-101)
112
Ae.5.Rf Driver Printed Circuit Board 85-131-X
113
Ae.6.Crystal Switch Board 85-132-X
114
Ae.7.Het Osc, Driver Grid, and Driver Plate Switch Board 85-133-X
115
Af)Heathkit Linear Master Oscillators (Lmos)
116
Af.1.Lmo Part Numbers & Usage
116
Af.1.1.Heathkit TRW LMO
117
Af.1.2.Lmo Part Number 110-13
118
Af.1.3.Lmo Part Number 110-32
119
Af.1.4.Lmo Part Number 110-40
120
Af.1.5.Sb-102 LMO (Ver6)
121
Af.2.Lmo Repair and Service Notes
122
Af.2.1.Lmo Remove and Replace
122
Af.2.2.Heath Tube-Type LMO Repair
124
Af.2.3.Photos Showing Added Grounding Braid
127
Af.2.4.Repairing and Recalibrating a Stuck LMO
130
Af.2.5.Heathkit SB-102 Transceiver LMO Stability Fix
132
Ag)Matching Heathkit Paint
133
Ag.1.1.Matching Heathkit Paint: Part 1
133
Ag.1.2.Matching Heathkit Paint: Part 2
134
Ag.1.3.Matching Heathkit Paint: Part 3
135
Ah)Hw-101 and SB-10X Service Bulletins
136
Ah.1.Hw-101 Service Bulletins
136
Ah.1.1.Hw-101-1: VFO Drift
136
Ah.1.2.Hw-101-2: Repeated Heterodyne Oscillator Tube Failure Inadequate USB-LSB Frequency Shift
136
Ah.1.3.Hw-101-3: Carrier Null Control Failure
136
Ah.1.4.Hw-101-4: Low Output on 40 Meters
136
Ah.1.5.Hw-101-4: Low Output on 40 Meters
137
Ah.1.6.Hw-101-5: Alternate Method of Neutralizing the Final Amplifiers
137
Ah.1.7.Hw-101-5: Alternate Method of Neutralizing the Final Amplifiers
137
Ah.1.8.Hw-101-6: SB & HW Series Audio Preamplifier & VOX Circuit Troubleshooting Guide
138
Ah.1.9.Hw-101-7: SB & HW Series Instability & Corrective Information
138
Ah.1.10.Hw-101-8: Oscillations or Low Drive
138
Ah.1.11.Hw-101-9: Self Oscillations Occurring after Installation of Steel Comb Brackets
139
Ah.1.12.Hw-101-10: S-Meter Drift
139
Ah.1.13.Hw-101-11: Low Receiver Sensitivity
139
Ah.1.14.Hw-101-12: Improperly Manufactured 6HS6 Tubes
139
Ah.1.15.Hw-101-13: Germanium Diode Change
139
Ah.1.16.Hw-101-14: Improve ALC Adjustment
140
Ah.1.17.Hw-101-15: Driver and Mixer Switch Shields will Not Take Solder
140
Ah.1.18.Hw-101-16: Side Tone too Loud
140
Ah.1.19.Hw-101-17: Transceiver Oscillates in Transmit with the MIC Keyed
140
Bands
141
Ah.1.21.Hw-101-16: VFO Shift
141
Ah.1.22.Hw-101-20: Low Power Output, S-Meter Drift, Etc
141
Ah.1.23.Hw-101-21: Distorted Audio, no Carrier Null or Erratic Power Output in Voice Mode
141
Ah.1.24.Hw-101-22: Relative Power Meter Pegs on 15 and 10 Meter
142
Ah.1.25.Hw-101-23: Relays Remain Energized after Transmit Condition
142
Ah.1.26.Hw-101-24: Poor AGC Action
142
Ah.1.27.Hw-101-25: 100 Khz Calibrator Spurs
142
Ah.1.28.Hw-101-26: Receiver Recovery Slow
143
Ah.1.29.Hw-101-27: Erratic VFO Tuning
143
Ah.1.30.Hw-101-28: Carrier Nulls with C14 Trimmer Plates Completely Meshed
143
Ah.1.31.Hw-101-29: Poor Preselector Tracking
143
Ah.1.32.Hw-101-30: Poor Preselector Tracking
143
Ah.1.33.Hw-101-30: Loading Capacitor Turns as Plate Capacitor Is Rotated
144
Ah.1.34.Hw-101-30: Loading Capacitor Turns as Plate Capacitor Is Rotated
144
Ah.1.35.Hw-101-31: Relays Chatter in VOX Mode
144
Ah.1.36.Hw-101-32: "Chirping" and Slow Receiver Recovery
144
Ah.1.37.Hw-101-33: ALC Meter Reads below Zero
145
Ah.1.38.Hw-101-34: S Meter Drift
145
Ah.1.39.Hw-101-35: Poor if Sensitivity
145
Ah.1.40.Hw-101-36: Receiver Recovery Slow
145
Ah.1.41.Hw-101-37: R-940 Shorting to Shield
145
Ah.1.42.Hw-101-38: Poor Carrier Suppression
145
Ah.1.43.Hw-101-39: Identification of the 6146A Tubes
146
Ah.1.44.Hw-101-40: Noise or Static from Speaker When Chassis Tapped Lightly
146
Ah.1.45.Hw-101-41: Relay Chatter in any Setting of the VOX Sensitivity Control
146
Ah.1.46.Hw-101-42: Unit "Warbles" When Chassis Is Tapped
147
Ah.1.47.Hw-101-43: Poor Sensitivity or Grid or Plate Driver Coils will Not Tune
147
Ah.1.48.Hw-101-44: no Ground Pin on Tube Sockets at V10 and V11
147
Ah.1.49.Hw-101-45: VFO will Not Adjust Properly
147
Ah.1.50.Hw-101-46: Low Power Output; Poor VOX Sensitivity
147
Ah.1.51.Hw-101-47: Driver Preselector Won't Peak for Full Output at 7.0 MHZ
148
Ah.1.52.Hw-101-48: PEC [PN 84-22] no Longer Used
148
Ah.1.53.Hw-101-49: Changeover to 6146B Finals
148
Ah.1.54.Hw-101-50: R940 Overheats
148
Ah.1.55.Hw-101-51: Operation of Mode Switch Trips VOX
148
Ah.1.56.Hw-101-52: VFO Stops Working at High End of All Bands
149
Ah.1.57.Hw-101-53: Low Transmitter Output; Low Receiver Sensitivity
149
Ah.1.58.Hw-101-54: Receiver Audio Troubleshooting Information
149
Ah.1.59.Hw-101-55: AVC Decay too Fast; S Meter Drops too Quickly
150
Ah.1.60.Hw-101-56: Low Grid Drive on Certain Portions of One or more Bands
150
Ah.1.61.Hw-101-57: Relay Chatter in VOX Mode
151
Ah.1.62.Hw-101-58: Receiver Oscillations
152
Ah.1.63.Hw-101-59: Finals will Not Neutralize; C913 at Maximum Capacity
152
Ah.1.64.Hw-101-60: RF Mod in CQ Magazine
152
Ah.1.65.Hw-101-61: Parasitic Oscillations
153
Ah.1.66.Hw-101-62: Phase Shift Circuit Board Parts List
153
Ah.1.67.Hw-101-63: VOX Delay too Short
154
Ah.1.68.Hw-101-64: Load Control Squeaks with the HW-101-30 Mod Installed
154
Ah.1.69.Hw-101-65: CW Sidetone Inoperative
154
Ah.1.70.Hw-101-66: Rotary Switch Detent Change
154
Ah.1.71.Hw-101-67: Cannot Zero S Meter with the Meter Zero Control
155
Ah.1.72.Hw-101-68: Wiring for Use with the HD-15 Phone Patch
155
Ah.1.73.Hw-101-69: no Power Output in USB or LSB; Tune Okay
155
Ah.1.74.Hw-101-70: Sidetone Is too Loud
155
Ah.1.75.Hw-101-71: the #266-1116 Switch Detent Breaks During Installation
156
Ah.1.76.Hw-101-72: VOX Cycling
156
Ah.1.77.Hw-101-73: Tone in Audio When Switch to CW; Relay Chatters When Key Is Closed
156
Ah.1.78.Hw-101-74: Keys Continuously When Used with the SA-5010 Memory Keyer
157
Ah.1.79.Hw-101-75: R940 Overheats
157
Ah.1.80.Hw-101-76: Carrier Null Control Installation Change
157
Ah.1.81.Hw-101-77: VFO Stops Oscillating at High End of Dial
157
Ah.1.82.Hw-101-78: Tune Control Slips
158
Ah.1.83.Hw-101-79: Driver Stage Oscillates on 15 Meters
158
Ah.1.84.Hw-101-80: Low Transmitter Output Due to Low VFO Output
158
Ah.1.85.Hw-101-81: Preselector Capacitors Won't Take Solder
159
Ah.1.86.Hw-101-82: S Meter Drifts; if Oscillates
159
Ah.1.87.Hw-101-83: Oscillation on 15 Meters
159
Ah.1.88.Hw-101-84: R1, R6 and R7 out of Tolerance or Open
159
Ah.1.89.Hw-101-85: VOX Activates When Mike Not Connected
160
Ah.2.Sb-100 Service Bulletins
161
Ah.2.1.Sb-100-1: Diode Leakage in the SB-100, SB-101, HW-100
161
Ah.2.2.Sb-100-2: Alternate Method of Neutralizing the Final Amplifiers
161
Ah.2.3.Sb-100-3: SB & HW Series Audio Preamplifier & VOX Circuit Trouble Shooting Guide
162
Ah.2.4.Sb-100-4: SB & HW Series Instability and Corrective Information
163
Ah.2.5.Sb-100-5: Oscillations or Low Drive
165
Ah.2.6.Sb-100-6: Self Oscillations Occurring after Installation of Steel Comb Brackets
165
Ah.2.7.Sb-100-7: S-Meter Drift
165
Ah.2.8.Sb-100-8: Transmitter Oscillates in Transmit with the MIC Keyed
165
Ah.2.9.Sb-100-9: Tuning Erratic
166
Ah.2.10.Sb-100-10: Relays Remain Energized after Transmit Condition
166
Ah.3.Sb-101 Service Bulletins
167
Ah.3.1.Sb-101-1D: Driver Oscillates on 40 Meters
167
Ah.3.2.Sb-101-2D: Switch Action Improvement
167
Ah.3.3.Sb-101-3D: Improper Tuning
167
Ah.3.4.Sb-101-4D: Improper Tuning on 40Meters
167
Ah.3.5.Sb-101-5D: Grounding Problems on Transceivers
168
Ah.3.6.Sb-101-1: Meter Zeroing
168
Ah.3.7.Sb-101-2: Repeated Heterodyne Oscillator Failure
168
Ah.3.8.Sb-101-3: SB & HW Series Audio Amplifier & VOX Circuit Trouble Shooting Guide
169
Ah.3.9.Sb-101-4: Diode Leakage in the SB-100, SB-101, HW-101
170
Ah.3.10.Sb-101-5: SB & HW Series Instability & Corrective Information
170
Ah.3.11.Sb-101-6: Alternate Method of Neutralizing the Final Amplifiers
172
Ah.3.12.Sb-101-7: Oscillations or Low Drive
173
Ah.3.13.Sb-101-8: Self Oscillations Occurring after Installation of Steel Comb Brackets
173
Ah.3.14.Sb-101-9: S-Meter Drift
173
Ah.3.15.Sb-101-10: Low Receiver Sensitivity
173
Ah.3.16.Sb-101-11: Transceiver Oscillates in Transmit with MIC Keyed
174
Ah.3.17.Sb-101-12: Tuning Erratic
174
Ah.3.18.Sb-101-13: Relays Remain Energized after Transmit Condition
174
Ah.4.Sb-102 Service Bulletins
175
Ah.4.1.Sb-102-1: Meter Zeroing
175
Ah.4.2.Sb-102-2: Repeated Heterodyne Oscillator Tube Failure
175
Ah.4.3.Sb-102-3: Low Grid Drive - Alignment Problems
175
Ah.4.4.Sb-102-4: LMO Instability
176
Ah.4.5.Sb-102-5: Low 40 Meter Output
176
Ah.4.6.Sb-102-6: SB & HW Series Audio Preamplifier & VOX Circuit Trouble Shooting Guide
177
Ah.4.7.Sb-102-7: SB & HW Series Instability & Corrective Information
178
Ah.4.8.Sb-102-8: Alternate Method of Neutralizing the Final Amplifiers
179
Ah.4.9.Sb-102-9: Oscillations or Low Drive
180
Ah.4.10.Sb-102-10: Self Oscillations Occurring after Installation of Steel Comb Brackets
180
Ah.4.11.Sb-102-14: Relays Remain Energized after Transmit Condition
180
Ah.4.12.Sb-102-15: Poor AGC Action
181
Ah.4.13.Sb-102-16: 100KHZ Calibrator Spurs
181
Ah.4.14.Sb-102-17: Poor Preselector Tracking
181
Ah.4.15.Sb-102-18: Carrier Nulls with C14 Trimmer Plates Completely Meshed
181
Ah.4.16.Sb-102-19: Relays Chatter in VOX Mode
182
Ai)Using an HW-101 as a 100-Watt PA
183
Ai.1.The Basic Mod
184
Ai.2.The Enhanced Mod
185
Ai.3.Adjustment
185
Aj)Tube Substitutes
187
Ak)Tube Test Data
188
Other manuals for Heathkit HW-100
Assembly And Operation
112 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Heathkit HW-100 and is the answer not in the manual?
Ask a question
Heathkit HW-100 Specifications
General
Brand
Heathkit
Model
HW-100
Category
Transceiver
Language
English
Related product manuals
Heathkit HW-101
19 pages
Heathkit HW-104
236 pages
Heathkit HW-16
90 pages
Heathkit HW-9
146 pages
Heathkit SB-10 Series
190 pages
Heathkit SB100
9 pages
Heathkit SB102
9 pages
Heathkit SB-101
190 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
