Vent Components Diagrams (con’t)
DVP-TB1
Basement Vent Cap
12 in.
1-1/2 in.
7-3/8 in.
14 in.
17-3/4 in.
10-1/2 in.
3-7/8 in.
DVP-TV
Vertical Termination Cap
13-1/4 in.
24-5/8 in.
27-1/2 in.
RF6M
RoofFlashing Multi-pak
31 in.
24-5/8 in.
13-1/4 in.
RF12M
RoofFlashing Multi-pak
7-1/4 in.
5-1/4 in.
12-1/2 in.
DVP-TVHW
Vertical Termination Cap
(High wind)
BEK
Trap Cap Brick Extension
13-3/4 in.
5in.
13-3/4 in.
DRC-RADIUS
Cap Shield
13-7/8 in.
9-1/2 in.
14 in.
COOL-ADD
Cap Shield
11-5/8 in.
5-3/4 in.
7-1/8 in.
12-1/8 in.
PVK-80
(For use with IPI and DSI appliances only.)
