Heatilator EC36 - Fireplace Dimensions

6 17339 Rev L 08/04
EC SERIES INSTALLATION INSTRUCTIONS
Fireplace Dimensions
OUTSIDE AIR KIT
AK14
Cat. # A B C D
E/EC36 36 in. [914mm] 41 in. [1041mm] 25-1/4 in. [641mm] 12-5/8 in. [321mm]
E/EC39 39 in. [991mm] 44 in. [1118mm] 28-1/4 in. [718mm] 14-1/8 in. [359mm]
E/EC42 42 in. [1067mm] 47 in. [1194mm] 31-1/4 in. [794mm] 15-5/8 in. [397mm]
