LCD Symbols
Clock Indicator
Heat Active Indicator
Frost Mode On
Floor Temperature Over Limit
KeyLock On
1.Installation
1. The thermostat is flush mount, a back box of 35mm
should have been sunk in the wall prior to installation.
2. The thermostat should be mounted at around 6ft or
eye level.
3. Do not install near a direct heat source.
S
tep 1
Carefully separate the front half of the thermostat from
the back plate by placing a small flat head
terminal driver in to the slots on the bottom face of the
thermostat.
3
4
