Section Header
Model: Slimline-RF
12
• Press Clock repeatedly until you see feature 06 (Receiver Type) .................
The options within feature 06 are: 00 = UH8-RF or 01 = RF-Switch receiver.
• Use the Up/Down keys to set feature 06 to 00 (UH8-RF) ...............................
• Press Clock again until you see feature 07 (UH8-RF Board Address) .........
• Use the Up/Down keys to set the large digits to the board address of
the UH8-RF. This is the number set on the UH8-RF rotary switches ...........
(You must set a unique board address for each UH8-RF installed).
• Press Clock again until you see feature 08 (Zone number, 01-08) ..............
• The UH8-RF is an 8 zone receiver.
Use the Up/Down buttons to select the zone this thermostat
should be linked to ....................................................................................................
• Press Clock again until you see feature 09 ..........................................................
(00 = Underfloor heating, 01 = Radiators.)
• Use the Up/Down buttons to specify whether the thermostat is
controlling underfloor heating or radiators .......................................................
• Press A to confirm settings and the display will go blank .............................
• Press the Power button once to turn the thermostat back ON ...................
• Press the Up key to set the target temperature above the room
temperature; the flame symbol will appear and the assigned
zone on the UH8-RF will be activated ................................................................
This indicates pairing between the thermostat and the UH8-RF is successful.
