3. Technical specifications
3.1 Technical data:
100 indirect
120 indirect
150 indirect
170 indirect
210 indirect
250 indirect
250 indirect
300 indirect
300 indirect
Max direct kW rating @240v 3 3 3 3 3 3 6 3 6
Coil surface area m2 0.58 0.58 0.72 0.79 0.79 0.79 0.79 0.79 0.79
Coil rating (kW) 15l/min 15.2 15.4 15.9 17.3 19.2 18.6 18.6 18.8 18.8
Indirect heat time
(mins)
15l/min 24 24 29 30 34 42 42 49 49
Heat loss (kWh in 24h) / Day 1.14 1.25 1.45 1.63 1.91 2.22 2.22 2.52 2.52
Weight full (kg)
Weight empty (kg)
125 147 184 203 251 300 300 360 360
25 27 31 33 41 50 50 60 60
Max supply pressure 1.6MPa (16 bar)
Max design pressure 0.8MPa (8 bar)
Max operating pressure (PRV) 0.35MPa (3.5 bar)
Expansion relief valve setting 0.6MPa (6 bar)
T&P valve setting 1.0MPa (10 bar)/90°C
Maximum primary pressure 1.0MPa (10 bar)
Presure drop across coil 0.02MPa (0.2bar)
Notes:
1. Indirect cylinders tested in accordance with BS EN 12897:2006.
2. Heat up time from cold through 45°C, based on a flow temperature of 80°C +/- 2°C & normal volume.
3. Although the primary coil pressure rating is 1.0MPa (10bar) the 2 port zone valve and coil compression
nuts supplied with the cylinder is only rated 0.86MPa (0.86 bar). If the cylinder is to be plumbed into a
system delivering 1.0MPa (10 bar) a suitable 2 port zone valve and the coil compression nuts supplied will
have to be sourced.
Table 1: Technical data - Indirect
