9
L
N
1 2 3
Control Housing Details
Element Connections
1.5mm² 3 Core
HOFR sheathed
cable
Indirect control
wiring
N
L
1.5mm² 3 Core
HOFR sheathed
cable
Figure 5: Direct wiring schematic
Figure 4: Indirect wiring schematic
