• Do not throw away packaging materials until you have not reviewed carefully if they did
not remain a part of the product. If possible, keep the container for future use (storage
generator, transport...).
• Parts of the packaging (plastic bags, paper clips, etc.) do not leave within reach of
children, could be a possible source of danger.
• Disposal must be made in accordance with the regulations in force in the country in which
the equipment was installed.
• Make sure that bags and containers of plastic material are left strewn freely in the
environment because they pollute it.
• If you have any doubt do not use the machine, but have it checked by an authorized
service center.
ASEMBLY
The device is supplied assembled, the only unassembled part is protective cover. Mount it by
using 4 screws and washers (see figure 1)
BEFORE STARTING THE MACHINE
• Do not start the machine until you have made yourself familiar with these operating
instructions and all the safety instructions. If you have no experience in handling these
machines, you should obtain assistance from an experienced person.
• All covers and safety equipment must be properly installed and the saw blade must run freely.
• Check the entire machine and al cables for any signs of transport damage.
• Check that the saw blade is secured, not dirty, undamaged and sharp. Sharpen or replace
blunt saw blades.
• Check that all the screw connections are tight.
• Check the machine for any foreign bodies that may be catapulted out of it.
i
Important: It is essential that other persons remain a safe distance from the saw
whilst it is operating.
• Do not attempt to saw more than one piece of wood or bundles of wood at the same
time –this poses a serious risk of injury. Place bent pieces of wood in the feed carried so
that the side that is bent outwards faces the saw blade.
• Before you press the ON/OFF switch), make sure that the saw blade is fitted correctly and
that the machine’s moving parts run smoothly.
CHANGING THE DIRECTION OF ROTATION
Depending on the phase sequence, it is possible that the electric motor will turn in the wrong
direction. If the electric motor turns in the wrong direction, the saw cannot be operated. If
such case, the phase changer setting must be changed:
1. Install machine ready for work and connect it to the power supply.
2. To check for this condition, start the saw (press the GREEN switch). If the splitting knife does
not move, turn off the machine (press the RED switch).
3. Unplug the power cable at the splitter.
4. There is a direction button which can control the rotating direction of motor on the
magnetic switch (fig. 2).
5. Turn the machine on again
