Control Settings
Volume
The output volume rotary switch changes the reproduction level in a ± 12 dB range. We
recommend to ne-tune the volume through the connected source like an interface,
control board, mixing board or pre-amp.
The output volume allows to match the speakers to the audio chain, e.g. lowering SNR or
THD. The default setting is 0 dB.
VOL. [dB] LINEARISER
®
CoP
-2
-4 +4
+2
0
LOW
-2
-4 +4
+2
0
HIGH
EXTEND.
(less SPL)
NORMAL
for SUB (80 Hz)
MONO
LEFT
ANALOG
RIGHT
-4 +4
0
-10
SMALLLARGE
OFF
MED.
-6
-12 +12
+6
0 ON
OFF
(*)
Ported
Closed
SHELVING FILTER [dB] LF RANGE
ANALOG/AES INP. SENS. [dB] DESK FILTER
ALL "0" and "↑" POSITION = FACTORY SETTING
