Translation of the original instructions / Small animal clipper 19
8 Spare parts
See illustration spare parts at the end of this instruction manual.
WARNING!
Faulty spare parts may cause damages, malfunctions or total loss and may
reduce security. Therefore:
X
Only use original spare parts from the manufacturer. Purchase the spare
parts at the ocial distributor or directly at the manufacturer.
X
If using no original spare parts all warranty and service claims are ex-
piring.
Pos.
No.
Description Qty. Pos.
No.
Description Qty.
1 Complete housing set 1 20 Clamp holder 1
3 Li-Ion battery 7.4 V / 1.6 Ah 1 21 Top blade 1
4 Motor complete 1 22 Bottom blade 1
5 PCB clipper 1 23 Screw M3,5x4 2
6 Rubber tap 1 24 Charging station upper hous-
ing part
1
7 Turning lever 1 25a PCB charging station 1
8 Seal 1 25b Power supply with plug 1
9 Circlip Ø3.2 1 26 Charging station base plate 1
10 Washer Ø4x0.5 1 27 Rubber foot 4
11 Eccentric cogwheel, pre-as-
sembled
1 28 Plug EU 1
14 PT-screw Kombitorx
KA30x16
12 29 Plug AU Type 1
Plug AU/ARG Type 2
1
15 Blade support 1 30 Plug GB 1
16 Blade interlock red 1 31 Plug US Type 1
Plug US-JP Type 2
1
17 PT-screw Kombitorx KA30x8 1 32 Charging station with/without
power supply unit and plug
1
18 Clipping pressure spring 1 33 Plug KR 1
19 Blade guide 1 34 Plug BR 1
9 Disposal
CAUTION!
Environmental damages when disposing incorrectly!
Electronic scrap, batteries, lubricants and other indirect materials are sub-
ject to hazardous waste treatment and may only be disposed of by approved
specialist companies!
NOTE!
For disposal hand the clipper and charging station over to a nearby service
centre or specialist shop for electronics.
