Fig.7-8 Control Panel of Air-condition
Notice：
a) The battery can produce combustibility air, it has explosion danger, it
must be forbidden short circuit, light and fireworks.
b) The electrolyte is a sparse vitriol, it is danger if skin or eye touches it. If
shin touches electrolyte, it must be flush with the water immediately. While eye
touches it, flush with water and see a doctor immediately.
Attachment：wiring harness show in Fig. 7-9~7-11.
The GY, GR, GW, WB, YR, RY, RB, LB etc. means a pair of colors line, the
former have 2/3, the latter have 1/3.
B R G Y L W Br Lg P V
Black Red Green Yellow Blue White Brown
Pale
green
Pink Violet
