Main Specifications（1）
Model
Unit
CPD10
CPD15
CPD18
GC1Li
/GD1Li
GC1Li
/GD1Li
GC1Li /GD1Li
Rated capacity
kg
1000
1500
1750
Load center
mm
500
Lifting height
mm
3000
Free lifting height
mm
145
Mast tilt angle (fwd/bwd)
(α/β)
°
6/8
Fork size (T×W× L4)
mm
32×100×770
35×100×920
Wheelbase L1
mm
1380
Tread (front/rear) (W3/W2)
mm
910/920
Overall length (without
forks) L’
mm
2070
Overall width W1
mm
1086
Overall height
(mast/overhead guard)
(H1/H4)
mm
1985/2130
Seat height
mm
1080
Under-clearance (H5/H6)
mm
90/80(in the middle of the
truck body)
80/75(in the middle
of the truck body)
Min. turning radius r
mm
1750
fork adjustment range
(outside) Max/min W5
mm
960/200
Travelling speed
(loaded/unloaded)
km/h
15/16
Lifting speed
(loaded/unloaded)
mm/s
DC: 290/450
270/450
280/530
AC: 410/600
400/600
380/600
Descending speed
(loaded/unloaded)
mm/s
400/500
Gradeability
(loaded/unloaded)
%
20/25
19/24
17/22
Tyre (front/rear)
6.00-9-10PR/16×6-8-10PR
6.00-9/16×6-8-10PR
Traction motor power
kW
8.2 (AC)
7.5(DC)
8.6(DC)
Pump motor power
kW
10.6 (AC)
Battery
V/Ah
48/400(standard)
48/500(optional)
Service weight (with/without
battery)
kg
2700/2350
2955/2605
3105/2755
Battery weight
kg
350
