HELI CPD18 User Manual

9
Main Specifications（3）
Model
Unit
CPD30
CPD35
GC1Li/GD1Li/GD3Li
GC1Li/GD1Li/GD3Li
Rated capacity
kg
3000
3500
Load center
mm
500
Lifting height
mm
3000
Free lifting height
mm
145
150
Mast tilt angle (fwd/bwd) (α/β)
deg.
6/10
Fork size (T×W× L4)
mm
45×125×1070
50×125×1070
Wheelbase L1
mm
1685
Tread (front/rear ) W3/W2
mm
1000/950
Overall length (without forks) L’
mm
2545
2550
Overall width (front/rear) W1
mm
1238
Overall height (mast/overhead guard)
(H5/H6)
mm
2075/2215
2180/2215
Seat height
mm
1165
Under-clearance (H1/H2)
mm
135（at mast ）/145（in the middle）
Min. turning radius r
mm
2240
2260
fork adjustment range (outside) Max/min
W5
mm
1060/250
Travelling speed (loaded/unloaded)
km/h
15/15.5
14.5/15
Lifting speed (loaded/unloaded)
mm/s
DC:280/460
270/440
AC:340/460
325/450
Descending speed (loaded/unloaded)
mm/s
-/500
Gradeability (loaded/unloaded)
%
17/20
15/20
Tyre ,front
28x9-15-12PR
28x9-15
Tyre, rear
18x7-8-14PR
18x7-8
Traction motor
kW
16.6 (AC)
Pump motor
kW
13 (DC)
13.5 (AC)
Battery
V/Ah
80/400（standard）
80/500, 80/600（optional）
Service weight(with/without battery)
kg
4760/4200
5330/4770
