HELI JS07N - Page 37

JS07N·JS07·JS08·JS12·JS14
35
Specification
JS12 Series(JS1212)
Max.working height ○
1
13.9m
Max.platform height○
2
11.9m
Overall height(guardrail unfolded)○
3
2.60m
Height stowed-rails folded○
4
1.98m
Overall width 1.15m
Overall length 2.40m
Platform Size(length Χ width) 2.25x 1.15m
Extension size of platform 1.0m
Rated capacity○
5
320kg
Ground clearance(retracted state) 95mm
Ground clearance(lifting state) 20mm
Overall weight(Different configura-
tions)○
6
2950kg
Battery○
7
4 Battery 6V 240Ah
(Li Battery 25.6V 220Ah)
Tyres size
Φ381×129
Max.work slop(forward and
backward/left and right)
3°/1.5°
Drive speed(retracted state) 3.2km/h
Drive speed(lifting state) 0.8km/h
JS14 Series
Max.working height 15.8m
Max.platform height 13.8m
Overall height(guardrail unfolded) 2.79m
Height stowed-rails folded 2.15m
Overall width 1.39m
Overall length 2.79m
Platform Size(length Χ width) 2.62 x 1.15m
Extension size of platform 1.0m
Rated capacity 320kg
Ground clearance(retracted state) 95mm
Ground clearance(lifting state) 20mm
Overall weight(Different configu-
rations)
3690kg
Battery 4 Battery 6V 260Ah
(Li Battery 25.6V 277Ah)
Tyres size
Φ381×129
Max.work slop(forward and
backward/left and right)
3°/1.5°
Drive speed(retracted state) 3.2km/h
Drive speed(lifting state) 0.8km/h
notes:
○
1
JS0612 8m
JS0812 10m
JS1012 12m
○
2
JS0612 6m
JS0812 8m
JS1012 10m
○
3
JS0612 2.21m
JS0812 2.3m
JS1012 2.46m
○
4
JS0612 1.55m
JS0812 1.71m
JS1012 1.84m
○
5
JS0612 550kg
JS0812 450kg
JS1012 320kg
○
6
JS0612 1980kg
JS0812 2460kg
JS1012 2820kg
○
7
JS0612
JS0812
JS1012
4*6V 180Ah
Li Battery25.6V 220 Ah
