JS07N·JS07·JS08·JS12·JS14
34
Specifications
JS0407NE Series
Max.working height 6.00m
Max.platform height 4.00m
Overall height(guardrail unfolded)
1.95m
Height stowed-rails folded 1.5m
Overall width 0.76m
Overall length 1.42m
Platform Size(length Χ width)
1.42 x 0.76m
Extension size of platform 0.6m
Rated capacity 230kg
Ground clearance(retracted
state)
60mm
Ground clearance(lifting state)
15mm
Overall weight(Different configura-
tions)
910kg
Battery 2 Battery 12V 85Ah
(Li Battery 25.6V 75Ah)
Tyres size
Φ230×80
Max.work slop(forward and
backward/left and right)
3°/1.5°
Drive speed(retracted state) 4.0km/h
Drive speed(lifting state) 0.8km/h
JS07 Series(JS0607)
Max.working height 7.8m
Max.platform height 5.8m
Overall height(guardrail unfolded) 2.09m
Height stowed-rails folded 1.84m
Overall width
1
0.76m
Overall length 1.84m
Platform Size(length Χ width)
1.65 x 0.76m
Extension size of platform 0.9m
Rated capacity 230kg
Ground clearance(retracted state) 60mm
Ground clearance(lifting state) 20mm
Overall weight(Different configura-
tions)
1480kg
Battery 4 Battery 6V 200Ah
(Li Battery 25.6V 150Ah)
Tyres size
Φ323×100
Max.work slop(forward and
backward/left and right)
3°/1.
Drive speed(retracted state) 4.0km/h
Drive speed(lifting state) 0.8km/h
notes:
1
JS0607W 0.81m
