4 Technical data
4.1 Mechanical data
Category Description
Dimensions approx. 141 mm x 98 mm x 35 mm (see Fig. 11)
Weight 440 g
Material Aluminum
25.50 9.50
59.20 25.40
110°
Cone of view
8.32
25.40
90
25.40
8.40 16.70
34.70
39.40
140.80
(IEC60947-7-1)
2-4 Nm
Ground stud M5
16.40 51.80
98.20
94.82
87.10
84.60
127 6.90
4x M5 x 8
max 8 Nm
52.75 20
11.85
7.50
15.20
16.36
33.30
13.40
47.60
77.91
max 0.6 Nm
UNC4-40
35
140. 80
Fig. 11: Dimension drawing
APS-R, APS-R-PoE
Technical data
Mechanical data
09.06.2017 17
The reproduction, distribution and utilization of this document as well as the communication of its contents to others
without express authorization is prohibited. Offenders will be held liable for the payment of damages.
All rights reserved in the event of the grant of patent, utility model or design.
