9.4 List of used IP ports
This list provides all network ports that are used by the APS. Most
of them are needed only with optional functions. Consult this list for
your firewall and router configuration.
Establishing communication direction
–
➨ APS
APS as server listens on the corresponding port for
incoming connection requests.
– APS
➨
APS as client requests a connection to the corre-
sponding port of a server.
– ➨ APS ➨
APS listen and request connections at the same
port.
Use Direction Port TCP/UDP Description
HTTP
(user interface)
➨APS 80 TCP Internal web server
DNS
(Domain Name System)
APS➨ 53 UDP/TCP Resolving IP for FQDN
NTP
(Network Time Protocol)
APS➨ 123 UDP Clock synchronization
Push Services
(SOAP/XML)
APS➨ 80
configurable
TCP Push data to server via http
Push Services
(SOAP/XML)
APS➨ 443
configurable
TCP Secure push data to server via
https
IBIS
(IBIS protocol over Ethernet
VDV300)
➨APS➨ 10076 UDP External request of values
IBIS
(IBIS protocol over IP VDV301)
➨APS➨ DMS:
8080
PCS:
8081
TCP External request of values
SNMP
(Simple Network Management
Protocol)
➨APS 161 UDP External request of values
FTP
(File Tranfer Protocol)
APS➨ 21
configurable
TCP Data recording upload
SFTP
(Secure File Tranfer Protocol)
APS➨ 22
configurable
TCP Data recording secure upload
Appendix
List of used IP ports
56 09.06.2017
