9 Appendix
9.1 Detection area
Maximum detection area depending on installation height
cm
Metric system
Inch Feet
Instal.
Height
Width Depth
Instal.
Height
Width Depth
Instal.
Height
Width Depth
190 167 140 74.8 65.7 55.1 6.23 5.48 4,59
200 191 160 78.7 75.2 63.0 6.56 6.26 5.25
210 215 180 82.7 84.6 70.9 6.89 7.05 5.90
220 238 200 86.6 93.7 78.7 7.22 7.81 6.56
230 262 220 90.6 103.1 86.6 7.54 8.59 7.22
240 286 240 94.5 112.6 94.5 7.87 9.38 7.87
250 310 260 98.4 122.0 102.4 8.20 10.17 8.53
260 334 280 102.4 131.5 110.2 8.53 10.96 9.18
280 381 320 110.2 150.0 126.0 9.18 12.5 10.5
300 429 360 118.1 168.9 141.7 9.84 14.07 11.81
320 477 400 126.0 187.8 157.5 10.50 15.65 13,12
340 524 440 133.9 206.3 173.2 11.15 17.19 14.43
360 572 480 141.7 225.2 189.0 11.81 18.76 15.74
380 620 520 149.6 244.1 204.7 12.46 20.34 17.06
400 667 560 157.5 262.6 220.5 13.12 21.88 18.37
9.2 Ordering Information
Product Description Order no. Old order no.
APS-R Advanced People Sensor
with local DC power supply
for ceiling heights from 2.0 m -
4.00 m
013.928-007 510239
APS-R-PoE Advanced People Sensor
with Power over Ethernet
for ceiling heights from 2.0 m -
4.00 m
013.929-007 510238
Product
Appendix
Ordering Information
52 09.06.2017
