Hellenbrand E3 - Series Conditioner & Brine Tank Assemblies

10
Item Description Qty Part #
1 Control Center-Metered 1 109370 Specify Size (see pages 13-17 for detailed components)
2 Top Diffuser 1 101539
3&4 Mineral Tank Assembly Item 3 only Item 4 only
Mineral Tank Distributor Assy
-024 8 x 44 1 109290 101505
-032 9 x 48 1 109291 101508
-032 10 x 44 1 109292 101505
-048 10 x 54 1 109293 101512
-064 12 x 52 1 109846 101510
5 Ion Exchange Resin * 101123 *See Specications for amount
6 Underbedding * 100983 *See Specications for amount
7 3/8” x 6” Brine Line 1 102671
8 a Brine Tank Assy (18x33) No Grid-Black 1 104409
b Brine Tank Assy (18x40) No Grid-Black 1 104415
9 a,b Brine Tank Cover 18” 1 Included with 8 a,b
10-14a Safety Brine Valve Assy 33” 1 101302
10 b,c Safety Brine Valve Assy 40” 1 101305
10 Cap, Brine Well 2 101365
11* Safety Brine Valve 1 101274
12 Float Assembly 1 101660
13 Air Check 1 101181
14 a Brine Well 33” 1 102876
b,c Brine Well 40” 1 102877
15 2-Piece Overow 1 102217
– Owners Manual 1 800540
SERIES CONDITIONER & BRINE TANK ASSEMBLIES
