29
Filter
The heater is fitted with a filter to protect the heating element from dust and dirt.
If the filter has been subjected to heavy use, this will impair the air performance. To keep the heater in
perfect condition, clean the filter once every six month minimum (depending on the place of use and
environment) with a vacuum cleaner. The filter is removable (see drawing). You can remove and
reassemble the filter from the left（back view). When reassembling, push the filter to the end until it
cannot move anymore.
Cleaning
• First, switch off the device, pull out the power plug from electrical outlet and let the heater cool down.
• Clean the air inlet and outlet grilles regularly from dust and dirt (depend from the use and the environment) at
least twice a year) with a vacuum cleaner, use the vacuum brush attachment.
• Use the soft cloth to wipe the dust from enclosure. Do not use water! Never immerse the
appliance or power cord, plug in water or other liquids! Danger to life!
• Do not use any abrasive or caustic cleaning agents! Do not use any flammable cleaning agents e.g. petrol or
spirit for cleaning the device, as they will damage the heater or can cause a fire hazard.
• If the appliance is not going to be used for some time, it should be protected against excessive dust and dirt.
• Keep the original box in which the heater was packed. Clean the heater according to the instructions for
Cleaning. Pack the heater in the original box and store it in a cool, dry place.
Technical data
Model Volt/
Frequency
Watt Product-
measure
(mm)
Protection
class
IP-grade
SHF 18 E
220-240V~50Hz
1510-1800 W
372x130x320mm
II IP24
Guarantee
If problems occur with the device never try to open or repair by yourself. Every intervention in the unit for the
change of original condition leads inevitable to the loss of the guarantee claim and could also result in damage to
property and injury to people. Contact the retailer where you have purchased the appliance. The guarantee for
this device is based on the guarantee instructions. Damages which occur to transport, overloading, natural
erosion, non observance of the mounting / operating instructions or improper treatment will be excluded from the
guarantee. Technical changes concerning the advancement are reserve.
CE-Marking:
The CE-mark shows that the unit meets all essential directives “Electromagnetic Compatibility” (Directive
2014/30/EU), “Low voltage directive” (Directive 2014/35/EU) and directive “RoHS” (2011/65/EU).
30
Information requirements for electrical local space heaters
(EU) 2015/1188
Model identifier(s): SHF 18 E
(HF18E)
Item Symbol
Value Unit Item Unit
Heat output Type of heat input, for electric storage local space
heaters only (select one)
Nominal
heat output
P
nom
1,6 kW manual heat charge control, with
integrated thermostat
NA
Minimum
heat output
(indicative)
P
min
0,18x10
-3
kW manual heat charge control with room
and/or outdoor temperature feedback
NA
Maximum
continuous
heat output
P
max,c
1,6 kW electronic heat charge control with room
and/or outdoor temperature feedback
NA
Auxiliary electricity consumption fan assisted heat output [no]
At nominal
heat output
el
max
NA kW Type of heat output/room temperature control
(select one)
At minimum
heat output
el
min
NA kW single stage heat output and no room
temperature control
[no]
In standby
mode
el
SB
0,18x10
-3
kW Two or more manual stages, no room
temperature control
[no]
with mechanic thermostat room
temperature control
[no]
with electronic room temperature control [no]
electronic room temperature control plus
day timer
[no]
electronic room temperature control plus
week timer
[yes]
Other control options (multiple selections possible)
room temperature control, with presence
detection
[no]
room temperature control, with open
window detection
[yes]
with distance control option [no]
with adaptive start control [no]
with working time limitation [no]
with black bulb sensor [no]
Contact details Heller Elektro-Hausgeräte GmbH
Mühlberger Straße 34
D – 04895 Falkenberg/Elster
