360093-1/H
i.Series™
Countertop: PC100i, PC900i, PC1200i Version A
Floor: PC2200i, PC3200i, PC4200i Version A
Horizon Series™
Countertop: PC100h, PC900h, PC1200h Version A
Floor: PC2200h, PC3200h, PC4200h Version A
Model
S/N
HELMER, INC. 14395 BERGEN BLVD., NOBLESVILLE, IN 46060 USA
PHONE (317) 773-9073 FAX (317) 773-9082
USA and CANADA (800) 743-5637
www.helmerinc.com
Platelet Incubator Operation Manual

Table of Contents

Other manuals for Helmer PC100h

Preview: Service Manual
Service Manual104 pages

Questions and Answers

  • M
    Mary BaileySep 23, 2025
    What to do if the main power switch is on, and the doors are closed, but the built-in platelet agitator is not agitating (PC4200i) in my Helmer Accessories?
    • S
      stacyrobinsonSep 23, 2025
      If the main power switch is on, and the doors are closed, but the built-in platelet agitator is not agitating, confirm the hinge cams are not damaged and replace if necessary. Also, confirm the door gaskets are sealing completely and replace the door gasket if necessary. Confirm that all circuit breakers are seated and push the circuit breaker to reset it if necessary.
  • J
    johnsonjamesAug 25, 2025
    How to fix inaudible alarms on Helmer Accessories platelet incubator?
    • J
      johnathan61Aug 26, 2025
      If your platelet incubator is in an alarm condition but the alarms are not audible, first verify that the audible alarms are not muted. If the time remaining on the Mute timer is greater than five minutes, change the Mute timer value to five minutes and wait until the timer resets. Also, check the volume and adjust it if necessary. Verify whether the active alarm should be communicated audibly and ensure that the audible alarm time delay has elapsed or change the alarm delay.
  • P
    paulwilliamsAug 27, 2025
    Why is the chamber temperature displayed incorrectly on my Helmer Accessories?
    • M
      Marisa Lopez MDAug 27, 2025
      If the chamber temperature displayed is higher or lower than the actual temperature, it may be because the monitor is not calibrated. Confirm the upper temperature probe is reading correctly and calibrate the probe if necessary. It could also be that the digital electronics are locked due to a power interruption; in this case, reset the monitoring system.
  • R
    Robert TaylorAug 27, 2025
    What should I do if the main power switch is on, but the temperature controller is not working on my Helmer Accessories?
    • F
      farrelldonnaAug 27, 2025
      If the main power switch is on, but the temperature controller is not working, check the connections between the terminal board and temperature controller, securing them if necessary. Also, confirm the terminal board is supplying power to the temperature controller. If needed, replace the temperature controller or terminal board.
  • L
    leebarryNov 22, 2025
    What to do if the main power switch is on but nothing is working on my Helmer Accessories?
    • H
      harttimNov 22, 2025
      If the main power switch is on, but nothing is working, here are some things to check: * Verify power at the outlet and repair or connect to a different outlet if necessary. * Check the condition of the power cord and replace it if it's in poor condition. Also, check that the voltage through the cord is appropriate, and replace the cord if it is not. * For all models except 115 V floor models, check that connections between the power cord and power connector are secure and that the voltage through the power connector is appropriate. Replace the power connector if it is not. * For 230 V countertop models and all 100/115 V models, confirm that all circuit breakers are seated. Push the circuit breaker to reset if necessary. * For 230 V floor models, verify the fuse has not blown an...
  • A
    Alexandria JonesSep 14, 2025
    What causes excessive water in the chamber of my Helmer Accessories?
    • M
      Mark JacksonSep 14, 2025
      Excessive water in the chamber can be caused by humid air entering the chamber. Confirm the platelet incubator is level and the doors are aligned, closing tightly, and sealing correctly.
  • P
    Philip MooreSep 12, 2025
    Why is the No Battery alarm activating sporadically on my Helmer Accessories?
    • M
      Meghan Armstrong DVMSep 12, 2025
      If the No Battery alarm is activating sporadically, replace the backup batteries for the monitoring system, as the battery voltage level on the backup batteries may be low.
  • F
    fordvictorSep 13, 2025
    Why is there excessive humidity on the doors of my Helmer Accessories?
    • J
      Joyce KellySep 13, 2025
      Excessive humidity on the doors can be caused by humid air entering the chamber. Confirm the platelet incubator is level and the doors are aligned, closing tightly, and sealing correctly. It can also be due to a high relative humidity around the platelet incubator, so confirm the platelet incubator is placed appropriately.
  • A
    Anthony RileySep 5, 2025
    How to improve the readability of the display on the Helmer Accessories monitoring system?
    • B
      Bradley FloresSep 5, 2025
      If the display on the monitoring system is hard to read, change the screen contrast.
  • C
    Christy DiazSep 3, 2025
    Why is the motion alarm active even though the platelet agitator is moving in my Helmer Accessories?
    • M
      Mark GoodmanSep 3, 2025
      If the motion alarm is active, but the platelet agitator is moving, it could be because a Horizon Series platelet agitator is installed, but the alarm for the corresponding position was not disabled. Disable the motion alarm for that position. If you have a model without a built-in platelet agitator, verify agitation information is being received on the platelet incubator’s monitoring system. Verify the data cable is connected securely to the platelet agitator and the corresponding port in the platelet incubator, and tighten the connections if necessary.

Summary

Incubator Safety Guidelines

Safety Label Identification

Explains safety-related labels found on the incubator.

General Safety Instructions

Provides essential safety instructions for using the incubator.

Electrical Safety Precautions

Details safety measures related to the incubator's electrical components.

Chemical & Biological Safety

Outlines procedures for safe handling of chemicals and biological materials.

Incubator Installation Guide

Installation Task Overview

High-level overview of tasks required for incubator setup and configuration.

Location Selection Guidelines

Connecting and Powering On;Off

Backup Power Configuration

i.Series Monitoring System Setup

Viewing System Settings

Customizing Unit and Format Settings

Alarm Setting Adjustments

Procedures for adjusting various alarm parameters and thresholds.

Horizon Series Alarm System Setup

Temperature Alarm Setpoint Management

How to view and adjust high/low temperature alarm thresholds.

Incubator Maintenance Procedures

Preventive Maintenance Schedule

Battery Testing and Replacement

Incubator Cleaning Procedures

Temperature Controller Calibration

Chamber Temperature Alarm Testing

Procedures for testing the high and low temperature alarm functions.

Troubleshooting Operational Issues

General Operation Troubleshooting

Troubleshooting common issues related to general incubator operation.

Chamber Temperature Troubleshooting

Diagnosing and resolving issues with chamber temperature accuracy.

Alarm Activation Troubleshooting

Troubleshooting unexpected or missing alarm activations.

Testing Problems

Condensation Problems
