360093-1/H
i.Series™
Countertop: PC100i, PC900i, PC1200i Version A
Floor: PC2200i, PC3200i, PC4200i Version A
Horizon Series™
Countertop: PC100h, PC900h, PC1200h Version A
Floor: PC2200h, PC3200h, PC4200h Version A
Model
S/N
HELMER, INC. 14395 BERGEN BLVD., NOBLESVILLE, IN 46060 USA
PHONE (317) 773-9073 FAX (317) 773-9082
USA and CANADA (800) 743-5637
www.helmerinc.com
Platelet Incubator Operation Manual

Table of Contents

Other manuals for Helmer PC2200h

Preview: Service Manual
Service Manual104 pages

Questions and Answers

  • M
    Mrs. Courtney MilesSep 23, 2025
    What to do if the main power switch is on, and the doors are closed, but the built-in platelet agitator is not agitating (PC4200i) in my Helmer Accessories?
    • R
      Robert VazquezSep 23, 2025
      If the main power switch is on, and the doors are closed, but the built-in platelet agitator is not agitating, confirm the hinge cams are not damaged and replace if necessary. Also, confirm the door gaskets are sealing completely and replace the door gasket if necessary. Confirm that all circuit breakers are seated and push the circuit breaker to reset it if necessary.
  • R
    Rebecca MoralesAug 25, 2025
    How to fix inaudible alarms on Helmer Accessories platelet incubator?
    • Z
      zacharyhodgeAug 26, 2025
      If your platelet incubator is in an alarm condition but the alarms are not audible, first verify that the audible alarms are not muted. If the time remaining on the Mute timer is greater than five minutes, change the Mute timer value to five minutes and wait until the timer resets. Also, check the volume and adjust it if necessary. Verify whether the active alarm should be communicated audibly and ensure that the audible alarm time delay has elapsed or change the alarm delay.
  • D
    Derek ClarkAug 27, 2025
    Why is the chamber temperature displayed incorrectly on my Helmer Accessories?
    • G
      Gina MeadowsAug 27, 2025
      If the chamber temperature displayed is higher or lower than the actual temperature, it may be because the monitor is not calibrated. Confirm the upper temperature probe is reading correctly and calibrate the probe if necessary. It could also be that the digital electronics are locked due to a power interruption; in this case, reset the monitoring system.
  • D
    David RobinsonAug 27, 2025
    What should I do if the main power switch is on, but the temperature controller is not working on my Helmer Accessories?
    • M
      Morgan JimenezAug 27, 2025
      If the main power switch is on, but the temperature controller is not working, check the connections between the terminal board and temperature controller, securing them if necessary. Also, confirm the terminal board is supplying power to the temperature controller. If needed, replace the temperature controller or terminal board.
  • M
    Maria SchultzNov 22, 2025
    What to do if the main power switch is on but nothing is working on my Helmer Accessories?
    • D
      David StuartNov 22, 2025
      If the main power switch is on, but nothing is working, here are some things to check: * Verify power at the outlet and repair or connect to a different outlet if necessary. * Check the condition of the power cord and replace it if it's in poor condition. Also, check that the voltage through the cord is appropriate, and replace the cord if it is not. * For all models except 115 V floor models, check that connections between the power cord and power connector are secure and that the voltage through the power connector is appropriate. Replace the power connector if it is not. * For 230 V countertop models and all 100/115 V models, confirm that all circuit breakers are seated. Push the circuit breaker to reset if necessary. * For 230 V floor models, verify the fuse has not blown an...
  • C
    Cheryl Simmons MDSep 14, 2025
    What causes excessive water in the chamber of my Helmer Accessories?
    • B
      Brian PriceSep 14, 2025
      Excessive water in the chamber can be caused by humid air entering the chamber. Confirm the platelet incubator is level and the doors are aligned, closing tightly, and sealing correctly.
  • A
    Aaron CabreraSep 12, 2025
    Why is the No Battery alarm activating sporadically on my Helmer Accessories?
    • N
      Natalie WilliamsSep 12, 2025
      If the No Battery alarm is activating sporadically, replace the backup batteries for the monitoring system, as the battery voltage level on the backup batteries may be low.
  • J
    Jody TuckerSep 13, 2025
    Why is there excessive humidity on the doors of my Helmer Accessories?
    • J
      Jessica RothSep 13, 2025
      Excessive humidity on the doors can be caused by humid air entering the chamber. Confirm the platelet incubator is level and the doors are aligned, closing tightly, and sealing correctly. It can also be due to a high relative humidity around the platelet incubator, so confirm the platelet incubator is placed appropriately.
  • E
    Erica FrazierSep 5, 2025
    How to improve the readability of the display on the Helmer Accessories monitoring system?
    • B
      Brian WilkersonSep 5, 2025
      If the display on the monitoring system is hard to read, change the screen contrast.
  • J
    joshua54Sep 3, 2025
    Why is the motion alarm active even though the platelet agitator is moving in my Helmer Accessories?
    • B
      Barbara PatrickSep 3, 2025
      If the motion alarm is active, but the platelet agitator is moving, it could be because a Horizon Series platelet agitator is installed, but the alarm for the corresponding position was not disabled. Disable the motion alarm for that position. If you have a model without a built-in platelet agitator, verify agitation information is being received on the platelet incubator’s monitoring system. Verify the data cable is connected securely to the platelet agitator and the corresponding port in the platelet incubator, and tighten the connections if necessary.

Summary

Working Safely

Understanding Safety-Related Labels

General Safety

Provides general safety instructions for users.

Electrical Safety

Details safety precautions related to electrical hazards.

Chemical and Biological Safety

Outlines safety practices for chemical and biological materials.

Installing the Incubator

Reviewing Installation and Configuration Tasks

Outlines the steps for installing and configuring the incubator.

Selecting an Appropriate Location

Provides guidelines for choosing a suitable location for the incubator.

Powering the Incubator

Explains how to connect and turn the incubator on and off.

Enabling Backup Power

Describes how to activate backup power systems for critical functions.

Configuring the Incubator Setpoint

How to set the desired temperature for the incubator chamber.

Preparing the Monitoring System on i.Series Incubators

Changing Alarm Settings

Options for modifying various alarm parameters.

Preparing the Alarm System on Horizon Series Incubators

Viewing and Changing the Setpoints for Temperature Alarms

Adjusting temperature alarm thresholds on Horizon Series models.

Maintaining the Incubator

Reviewing the Preventive Maintenance Schedule

Outlines recommended scheduled maintenance tasks and frequencies.

Testing and Replacing Batteries

Procedures for testing and replacing various incubator backup batteries.

Calibrating the Temperature Controller Readout

Adjusting the temperature controller to match actual chamber temperature.

Calibrating Temperature Readings on the i.Center

Calibrating temperature probes for the i.Center monitoring system.

Testing Chamber Temperature Alarms

Procedures for testing temperature alarms.

Testing the Power Failure Alarm

Procedure to test the power failure alarm functionality.

Testing the Motion Alarm

How to test the motion alarm for agitators.

Testing the Door Open Alarm

Procedure to test the door open alarm.

Testing the No Battery Alarm

Testing the alarm that indicates missing or low batteries.

Understanding and Addressing Operational Issues

Addressing General Operation Problems

Troubleshooting common operational issues and their causes.

Addressing Chamber Temperature Problems

Addressing Alarm Activation Problems
