360096-1/P
Platelet Incubator Service Manual
i.Series
®
and Horizon Series™
Countertop
i.Series
PC100i, PC900i, PC1200i
PC100h, PC900h, PC1200h
Floor
i.Series
PC2200i, PC3200i, PC4200i
PC2200h, PC3200h, PC4200h

Table of Contents

Questions and Answers

  • A
    Amanda GoodmanSep 23, 2025
    What to do if the main power switch is on, and the doors are closed, but the built-in platelet agitator is not agitating (PC4200i) in my Helmer Accessories?
    • J
      Jessica EdwardsSep 23, 2025
      If the main power switch is on, and the doors are closed, but the built-in platelet agitator is not agitating, confirm the hinge cams are not damaged and replace if necessary. Also, confirm the door gaskets are sealing completely and replace the door gasket if necessary. Confirm that all circuit breakers are seated and push the circuit breaker to reset it if necessary.
  • J
    Joanna HudsonAug 25, 2025
    How to fix inaudible alarms on Helmer Accessories platelet incubator?
    • C
      Candice PalmerAug 26, 2025
      If your platelet incubator is in an alarm condition but the alarms are not audible, first verify that the audible alarms are not muted. If the time remaining on the Mute timer is greater than five minutes, change the Mute timer value to five minutes and wait until the timer resets. Also, check the volume and adjust it if necessary. Verify whether the active alarm should be communicated audibly and ensure that the audible alarm time delay has elapsed or change the alarm delay.
  • H
    Howard BrownAug 27, 2025
    Why is the chamber temperature displayed incorrectly on my Helmer Accessories?
    • G
      Gerald PatrickAug 27, 2025
      If the chamber temperature displayed is higher or lower than the actual temperature, it may be because the monitor is not calibrated. Confirm the upper temperature probe is reading correctly and calibrate the probe if necessary. It could also be that the digital electronics are locked due to a power interruption; in this case, reset the monitoring system.
  • D
    Denise BakerAug 27, 2025
    What should I do if the main power switch is on, but the temperature controller is not working on my Helmer Accessories?
    • C
      Clinton KlineAug 27, 2025
      If the main power switch is on, but the temperature controller is not working, check the connections between the terminal board and temperature controller, securing them if necessary. Also, confirm the terminal board is supplying power to the temperature controller. If needed, replace the temperature controller or terminal board.
  • T
    Terry HardyNov 22, 2025
    What to do if the main power switch is on but nothing is working on my Helmer Accessories?
    • C
      Curtis BridgesNov 22, 2025
      If the main power switch is on, but nothing is working, here are some things to check: * Verify power at the outlet and repair or connect to a different outlet if necessary. * Check the condition of the power cord and replace it if it's in poor condition. Also, check that the voltage through the cord is appropriate, and replace the cord if it is not. * For all models except 115 V floor models, check that connections between the power cord and power connector are secure and that the voltage through the power connector is appropriate. Replace the power connector if it is not. * For 230 V countertop models and all 100/115 V models, confirm that all circuit breakers are seated. Push the circuit breaker to reset if necessary. * For 230 V floor models, verify the fuse has not blown an...
  • A
    arthurriosSep 14, 2025
    What causes excessive water in the chamber of my Helmer Accessories?
    • L
      Linda ContrerasSep 14, 2025
      Excessive water in the chamber can be caused by humid air entering the chamber. Confirm the platelet incubator is level and the doors are aligned, closing tightly, and sealing correctly.
  • S
    steven55Sep 12, 2025
    Why is the No Battery alarm activating sporadically on my Helmer Accessories?
    • J
      Juan WhiteSep 12, 2025
      If the No Battery alarm is activating sporadically, replace the backup batteries for the monitoring system, as the battery voltage level on the backup batteries may be low.
  • J
    jessica65Sep 13, 2025
    Why is there excessive humidity on the doors of my Helmer Accessories?
    • L
      Lisa FrancoSep 13, 2025
      Excessive humidity on the doors can be caused by humid air entering the chamber. Confirm the platelet incubator is level and the doors are aligned, closing tightly, and sealing correctly. It can also be due to a high relative humidity around the platelet incubator, so confirm the platelet incubator is placed appropriately.
  • C
    Christy ColemanSep 5, 2025
    How to improve the readability of the display on the Helmer Accessories monitoring system?
    • R
      Richard CampbellSep 5, 2025
      If the display on the monitoring system is hard to read, change the screen contrast.
  • A
    Amy FlynnSep 3, 2025
    Why is the motion alarm active even though the platelet agitator is moving in my Helmer Accessories?
    • J
      Jessica GreeneSep 3, 2025
      If the motion alarm is active, but the platelet agitator is moving, it could be because a Horizon Series platelet agitator is installed, but the alarm for the corresponding position was not disabled. Disable the motion alarm for that position. If you have a model without a built-in platelet agitator, verify agitation information is being received on the platelet incubator’s monitoring system. Verify the data cable is connected securely to the platelet agitator and the corresponding port in the platelet incubator, and tighten the connections if necessary.

Summary

Notices and Disclaimers

About this Manual

Safety Precautions and Symbols

Important safety symbols and their meanings used in the manual.

Installation and Configuration

Install Batteries for Backup Power

Procedure for installing backup batteries for power failure protection.

Temperature Monitor Settings

Calibrate Temperature Probes

Procedure for calibrating temperature probes for accurate readings.

Temperature Controller Setpoints

Platelet Incubator Setpoint

How to change the primary temperature setpoint.

Maintenance

Recharge Refrigerant

Procedure for recharging the unit's refrigerant.

Troubleshooting

General Operation Problems

Common issues and solutions for basic unit operation.

i.Series Parts

Front parts (multiple models shown)

Identification of front-mounted components and their part numbers.

Schematics

PC100 i, PC900 i, PC1200 i (100;115 V)

Electrical schematic for specific voltage and models.

i.Center Screen Reference

Home Screen

Navigation from the HOME screen.

i.Center Screen Reference

Main Screen

Options available from the MAIN screen.

i.Center Screen Reference

Edit Configuration

Accessing and changing system settings.

i.Center Screen Reference

System Options

Settings for language, alarms, and timers.

i.Center Screen Reference

Alarm Setpoints

Configuration of various alarm thresholds.

i.Center Screen Reference

Agitator Alarm Setpoints

Configuration of agitator motion alarm setpoints.

i.Center Screen Reference

Temperature Calibration

Procedure for calibrating temperature probes.

i.Center Screen Reference

Factory Default Settings

Restoring the unit to factory default settings.

i.Center Screen Reference

Event Log

Viewing historical alarm and operational events.

i.Center Screen Reference

Agitator Count Log

Viewing cycle counts for agitators.

Horizon Series Models

Installation and Configuration

Steps for installing and configuring Horizon Series models.

Alarm Settings

Temperature and Power Failure Alarm Volume

Adjusting alarm volume and delay.

Alarm Settings

Motion Alarm (PC4200 h)

Configuring the motion alarm delay and volume.

Alarm Settings

Alarm Tests

Procedures for testing various unit alarms.

Temperature Controller Setpoints (Horizon Series)

Level 1 Parameters and Values

Details on SP1 parameters for chamber heating control.

Temperature Controller Setpoints (Horizon Series)

Level 2 Parameters and Values

Details on SP1 and SP2 power limits and display settings.

Temperature Controller Setpoints (Horizon Series)

Level 3 Parameters and Values

Details on SP1/SP2 output types and software version.

Temperature Controller Setpoints (Horizon Series)

Level 4 Parameters and Values

Details on advanced parameters like security lock.

Change the Platelet Incubator Setpoint

How to change the primary temperature setpoint.

Temperature Controller Setpoints (Horizon Series)

Calibrate the Temperature Controller Display

Procedure to adjust the display for accurate readings.

Maintenance (Horizon Series)

Recharge Refrigerant

Procedure for recharging the unit's refrigerant.

Maintenance (Horizon Series)

Power Failure Alarm Battery

Testing and replacing the power failure alarm battery.

Maintenance (Horizon Series)

Motion Alarm Battery (PC4200 h)

Testing and replacing the PC4200h motion alarm battery.

Maintenance (Horizon Series)

Clean the Platelet Incubator

Instructions for cleaning the unit components.

Troubleshooting (Horizon Series)

General Operation Problems

Common issues and solutions for basic unit operation.

Troubleshooting (Horizon Series)

Chamber Temperature Problems

Diagnosing and resolving temperature stabilization issues.

Troubleshooting (Horizon Series)

Alarm Activation Problems

Troubleshooting why alarms are not audible or communicating.

Horizon Parts

Front parts (multiple models shown)

Identification of front-mounted components and their part numbers.

Schematics (Horizon Series)

PC100 h, PC900 h, PC1200 h (100;115 V)

Electrical schematic for specific voltage and models.

Schematics (Horizon Series)

PC100 h, PC900 h, PC1200 h (230 V)

Electrical schematic for specific voltage and models.

Schematics (Horizon Series)

PC2200 h (115 V)

Electrical schematic for specific voltage and models.

Schematics (Horizon Series)

PC2200 h (230 V)

Electrical schematic for specific voltage and models.

Schematics (Horizon Series)

PC3200 h (115 V)

Electrical schematic for specific voltage and models.

Schematics (Horizon Series)

PC3200 h (230 V)

Electrical schematic for specific voltage and models.

Schematics (Horizon Series)

PC4200 h (115 V)

Electrical schematic for specific voltage and models.

Schematics (Horizon Series)

PC4200 h (230 V)

Electrical schematic for specific voltage and models.
