a Unit serial number
(visible only when door open)
b Exhaust diverter
(gas appliances only, optional)
c Interior lighting
d Cabinet door with double glass panel
e Door handle
Table-top units: one-handed operation with slam
function
Floor units: (One-handed operation)
f Unlocking device to open double glass door
panel
(inside)
g Integral and self-draining door drip pan
(inside)
h Drip collector connected directly to
appliance drain
i Adjustable feet
j Unit data plate
(with all important data such as power input, gas
type, voltage, phase number and frequency, as well
as model and serial number, see also
Functions/Settings/ Type)
k Control panel
l Protective cover for electrical
installation area
m Hand shower
(with automatic rewind)
n Run-in guide
(floor models)
o Air filter
(installation area ventilation)
Features
- 9-
Applies to base-top models 061, 062, 101, 102.
Applies to floor models with roll-in carts 201 and 202.
