user manual INTEGRA
HENSEL Studiotechnik 8
6 Overview of Controls
1 ON:
Main Switch ON / OFF
2 FC:
Flash Check ON / OFF
3 Slave ON Indicator
4 READY:
Ready (for flash triggering) and Overheat Indicator
5 SLAVE:
Slave ON / OFF
6 TEST:
Manual flash release
7 230V/50-60 Hz / 115V/50-60 Hz:
Mains Connector
8 FULL / OFF / PROP:
Operation mode for modeling lamp
9 Flash Power control switch
10 Fuse for modeling lamp
11 Sliding switch
230 V / 115 V mains voltage
12 SYNC:
Synchronisation Socket
13 Slave
14 Reflector Quick-Change Mechanism
15 Tilting Head with integrated Umbrella Holder
7 Starting Up
Safety hints for operation with compact flash units
To avoid damage to the flashtube mount reflectors and
lightformers (softboxes etc.) before
use and turning on the
unit. Do not move compact flashes around, while they are
operating. Turn off the appliance for each change of reflectors
or to move the unit to another location.
Caution:
Reflectors, speedrings and other accessories heat up during
longer operation. To avoid injuries, handle with isolating cloth
or wait, till parts cooled down.
