user manual INTEGRA
HENSEL Studiotechnik 11
10 A
Bi-Voltage/230V:
2 AF
Bi-Voltage/115V:
4 AF
For removing the glass dome, please slightly tilt it again so
that it will easily slip out of the two fixing springs.
Then gently loose the glass dome from the remaining third
spring and remove it from the fixing device.
Mains connection
Attention:
Before connecting the compact flash unit to the mains outlet,
make sure, the mains voltage matches the information given on
the type label of the compact flash. The type label can be found
on the bottom of the appliance.
When you are operating with INTEGRA Bi-Voltage, make sure
that depending on the mains voltage the sliding switch 11 is in
the correct position.
The provided power cable will be attached to the mains socket
7 and then connected to mains outlets.
Compact flashes may only be connected to mains outlets
with ground connection.
Fuses
Outlets, in the building
Minimum requirement 10 A fuse outlets
Fuses of INTEGRA
The fuse 10 is a general fuse for the compact flash unit and the
modeling lamp.
Fuses listed below are valid for operation with modeling light
300 W Halogen:
For operation at 230 V mains voltage the Bi-Voltage version
must be equipped with a fuse 2 A fast (2 AF), for operation at
115 V mains voltage with a fuse 4 A fast (4 AF).
Before starting up the Bi-Voltage version check the
provided fuse! Make sure, that the position of the sliding
switch 11 corresponds to the mains voltage.
More information on page 14, Replacement of fuses.
