user manual INTEGRA
HENSEL Studiotechnik 13
TEST
READY
OFF
PROP
FULL
FC
The IR transmitter „Speed“ has to be attached to the camera.
The IR group A or B can be selected on the transmitter by a
slide switch.
The IR receiver „Speed“ has to be connected to the
synchronization socket 12. The same IR group A or B must be
set on the receiver by a slide switch.
Flashes can be triggered using the provided synchronization
cable or the camera hot shoe. The transmitter should
approximately be pointed towards the connected IR-receiver.
All compact flashes within one selected group are flashing.
Test flash
By pressing the button 6 test flashes can be released.
Flash power control
The desired flash power can be set steplessly using power
control 9. This covers a range of 5 f-stops.
Flash readiness
Flash readiness of the compact flash is shown by the green
light of the READY control lamp 4.
In the case of reducing the flash power, the yellow light of the
READY Indicator 4 turns on, till the flash power has been
dumped to the new level (READY Indicator green). It is also
possible, to reduce the stored energy by simply triggering a
TEST flash (press button 6).
Modeling lamp
You can select the operation mode for the modeling light by
positioning switch 8:
OFF
The modeling lamp is switched off.
PROP
The light output is proportional to the selected flash power.
FULL
The maximum light output of the modeling lamp is achieved.
Flash Check
If this mode is switched on turning switch 2 to „FC“ position,
then the modeling lamp is turned off after a flash and will turn
on after recharging to the adjusted power level. This shows
correct charge as well as readiness to flash. The flash check
mode guarantees that the flash heads have triggered when
more than one flash unit is used.
