user manual INTEGRA
HENSEL Studiotechnik 12
READY
SYNC
SLAVE
receiver and
transmitter
„Speed“
Overheating
All INTEGRA units are equipped with a fan to avoid overheating
with fast flash sequences, which could cause damage to the
flashtube and the compact flash unit. If overheating although
occurs, the unit turns off automatically. The red light of the
Overheat Indicator 4 turns on. After a break for cooling down,
the appliance is ready again for operation.
8 Operation
Synchronization (Flash triggering)
Synchronization by cable
The compact flash unit is connected to synchronization socket
12 to the camera using a synchronization cable with 6,3 mm
phone jack.
The synchronization circuit is made up of state-of-the-art semi-
conductor technology and enables secure triggering of the flash
even with older cameras with mechanical contacts.
Due to the many different electronical circuits in cameras for
controlling synchronization, we cannot take any liability for
possible damage to cameras triggering flashes.
Please contact the camera manufacturer before using an
unusual camera.
Synchronization by slave
The compact flash unit can be triggered by the built-in slave 13.
Triggering is then effected by an „incoming“ flash, which was
emitted by another flash light. This mode of operation is
switched on using switch 5 and displayed by the yellow light of
the SLAVE ON Indicator 3.
The slave is an impulse photocell. It can only operate, when the
triggering flash has a higher f-stop than the ambient light.
Please be aware that the ambient light which strikes the slave
may never be too strong. If this cannot be avoided, please
switch off the slave by pressing switch 5 and release the flash
by cable or IR.
Synchronization by infrared triggering system
For remote-controlled triggering, an infrared triggering system is
available as accessory:
IR Transmitter and Receiver „Speed“
Code 392 (Set) or 393 (Transmitter) + 394 (Receiver)
