HER CHEE GTC-50 - Page 70

ADLY MOTO 11-2
REAR WHEEL / SUSPENSION / BRAKE
Disassembly of Rear Wheel
Operation / Parts name Q’ty Remarks
1
2
3
4
5
Disassembly
Muffler
Hex washer face bolt
Hex head phillips bolt
Assembly of exhaust pipe
Collar
Gasket of exhaust pipe
2
2
1
1
1
6
7
8
Rear wheel
Nut
Plain washer
Rear wheel
1
1
1
Assembly
8→1
• Assembling with sequence in reverse
of disassembly.
