ADLY MOTO 12-5
ELECTRICAL DEVICE
Check Voltage of Battery
‧Remove helmet box mat and battery
cap , disassembly connection wires of
battery , check voltage between battery
terminals.
Charging sufficiently : over 12.8 V
Charging insufficiently : 11.5-12.8V
＊WARNNING:
Must check battery voltage with
digital voltmeter.
Check Charging System
Power leakage test
‧Disassembly ground guide wire from
battery after turning “OFF ” main
switch, next, connect voltmeter to the
end between terminal (–) & ground
guide wires.
‧Check voltage when main switch is
“OFF ”.
＊WARNNING:
‧Check voltage according to sequence
from big to small.
‧Voltmeter’s fuse will be broke when
check voltage over the under limitation
choosed.
‧No turn “ON” main switch when check
current.
Current Leakage : under 1 mA
