Hercules HE77 User Manual

Page 17For technical questions, please call 1-888-866-5797.Item 57673
Parts List (cont’d)
Part Description Qty
95 Ring 2
96 Knob 1
97 Flat Washer 1
98 HS Bolt 10
99 Fix Rail A 2
100 Friction Rule A 2
101 Fixed Seat 2
102 Sliding Plate 2
103 Cross Head Screw 2
104 Carry Handle 2
105 Back Rail 1
106 Nut 6
107 Big Flat Washer 6
108 Bolt 6
109 Fix Rail B 2
110 Friction Rule B 2
111 Working Table 1
112 Lock Plate 1
113 Table Insert 1
114 Protection Plate A 1
115 Protection Plate B 1
116 Bolt 6
117 Spring 2
118 Clip 2
119 Right Guard 1
120 Guard Bolt 4
121 Pin Cap 2
122 Ring 2
123 Pin 1
124 Limit Pin 1
125 Support Bracket 1
126 Left Guard 1
127 Pin 2
128 Handle 2
129 Screw 2
130 Washer 8
131 Cross Head Tapping Screw 6
132 Side Fence Cover B 1
133 Sid Fence Cover A 2
134 Pin 2
135 Fence Rear Cover 1
136 Position Clip 2
137 Position Plate 2
138 Fence 1
139 Fence Front Cover 1
140 Side Fence Cover C 1
141 Lock Plate 2
142 Fence Clip B 1
Part Description Qty
143 Fence Clip A 1
144 Side Fence 1
145 Miter Gauge Lock Handle 1
146 Miter Gauge 1
147 Lock A 1
148 Pointer 1
149 Sliding Bar 1
150 Front Rail 1
151 Pointer 1
152 Cap 1
153 Spindle Lock Plate 1
154 Main Body 1
155 Cover 1
156 Guide Pillar 2
157 Cross Head Screw 4
158 Cross Head Screw 2
159 Ball 8 1
160 Spring 1
161 Pin 6 2
162 Bolt 1
163 Spring 1
164 Sleeve 1
165 Motor 1
166 Ascent Adjusting Rod B 1
167 Key 2
168 Ascent Adjusting Bracket 1
169 Bevel Gear Wheel 2
170 Protection Plate 1
171 Adjusting Rod 1
172 Retaining Ring 2
173 Protection Plate 1
174 Screw B 2
175 Spring 1
176 Inner Flange 1
177 Miter Gauge Storage
178 Left Panel
179 Cord Sleeve 1
180 Cord & Plug 1
181 Switch 1
182 Switch Fix Bracket 1
183 Switch Lock 1
184 Cord Clamp 1
185 Spring 1
186 Lock Block A 1
187 Scale Label 1
188 Teeth Washer 1
189 Screw 1
