Page 16 For technical questions, please call 1-888-866-5797. Item 57673
PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Cross Head Tapping Screw 9
2 Emergency Stop Panel 1
3 Pin 1
4 Screw 1
5 Handle 1
6 Flat Washer 29
7 Wheel 1
8 Locknut 1
9 Pan Head Screw 3
10 Bevel Scale Label 1
11 Saddle Shape Washer 1
12 Lock Rod 1
13 Lock Handle 1
14 Big Flat Washer 3
15 Lock Washer 1
16 Pan Head Screw 9
17 Flat Washer 6
18 Angle Pointer 1
19 Front Panel 1
20 Big Flat Washer 9
21 Cross Head Tapping Screw 25
22 HS Bolt 2
23 Reinforced Panel 1
24 Eccentric Limit Block 2
25 HS Bolt 20
26 Spring Washer 24
27 Switch Box 1
28 Cord Clamp 1
29 Front-Left Foot,A 2
30 Main Frame 1
31 Front-Left Foot,B 2
32 Cross Head Tapping Screw 12
33 Back-Left Foot,A 2
34 Back-Left Foot,B 2
35 HS Bolt 8
36 Spring Washer 12
37 Flat Washer 14
38 Pad 4
39 Hex Bolt 1
40 Storage Clip Plate 1
41 Push Stick 1
42 Wing Nut 1
43 Wrench 1
44 Hex Thin Nut 4
45 Right Panel 1
46 Low Blade Guard Cover 1
47 Protection Plate 1
Part Description Qty
48 Bracket 2
49 Hex Thin Nut 1
50 Out Flange 1
51 Saw Blade 1
52 Bolt 1
53 Eccentric Handle 1
54 Cam Plate 1
55 Riving Knife 1
56 Spring 1
57 Paw 1
58 Washer 2
59 Ring 2
60 Pin Knob 1
61 HS Bolt 1
62 Plate 3
63 Limit Plate,B 1
64 Table Lock Spring 1
65 Elastic Pin 1
66 Lock Rod 1
67 Longer Nut,M8,B 1
68 Flat Washer 1
69 Bolt 1
70 Lock Handle 1
71 Lock Block A 2
72 Limit Plate A 1
73 Locknut 3
74 Washer 2
75 Table Locking Rod A 1
76 Longer Nut,M8 1
77 Lock Rod B,Assembly 1
78 Lock Link 2
79 Lock Rod C,Assembly 1
80 Bracket 1
81 Pin 1
82 Anti-Kick Back Palte Left 1
83 Spring 1
84 Pin 1
85 H.s.bolt 4
86 Adjusting Bracket,C 2
87 Adjusting Bracket 2
88 Spring 2
89 Pin 2
90 Rod 1
91 Gear 2
92 Nut 2
93 HS Bolt 4
94 Bracket A 2
