034-11401_1.0_24.08.2017
29
Description
4.4 Brake system
The bicycle's brake system comprises:
• a rim brake on the front and rear wheels.
4.4.1 Rim brake
Illustration 8: Components of the rim brake with details, example
1 Rear wheel brake
2Brake pad
3Brake arm
4 Rim
5 Handlebars with brake lever
6 Front wheel brake
The rim brake stops the movement of the wheel when
the rider pulls the brake lever, causing two brake pads,
positioned opposite one another, to be pressed onto
the rims.
There are two alternative versions of the rim brake:
• the hydraulically operated rim brake and
• the cable-operated rim brake.
